Hight Quality 3 ton Mini Folding Crane With CE
mini spider crane
1.Usage:electric power construction&glass installation
2.Used in narrow space.
Features:
1.Small crane , weight 2.1tons, Max. lifting weight 3 tons,the higest lifting weight 1 tons, Jib max. elongation 9m, max.lifting height 9.2m,max. operating radius 8.3m.
2.Folding crane with 4 legs.Leg expand max. size:L*W=4.3*3.4m;folded size:L*W*H=2.85*0.8*1.45M
3.Crawler crane:hydraulic drive when crawler walking, and gasoline drive or hydraulic drive when lifting.
Advantage:
♦Strong passing;Small weight and narrow body, especially suitable for indoor or confined places.
♦Good safety performance;the basic configuration has weight limiter.
♦High automation; Adopt joystick operation in multiple use while choose remote control, greatly improving lifting efficiency.
♦High technology; hydraulic systems in many places been used, guaranteeing the stability of lifting.
♦A quality product, which complies with CE regulations, export Europeen,Brazil etc.
♦Competitive pricing
♦After-care sales and service support
♦Product familiarisation and service training for customers.
♦12 months parts & labour warranty
♦Parts availability ex stock China
♦Sales literature, where feasible, in the local language
Model |
KB3.0 |
|
Specifications |
3.0t*1.3m |
|
Maximum operating radius |
8.3m |
|
Maximum raising height |
9.2m |
|
|
Winding |
Hook up speed |
2.5m/min(4) |
Cable diameter & length |
¢8mm*50m |
|
|
Telescopic |
Boom form |
5(5 Automatic) |
Boom length |
9m |
|
Up and downs |
Boom angle |
0-75° |
Rotation |
Rotation angle |
360-degree continuous rotation |
|
Outrigger |
The form of outrigger |
The first paragraph automatic |
Maximum extending range |
3.4m×4.3m |
|
|
Walking device |
Walk way |
Hydraulic |
Walking speed |
0-2.8km/h |
|
Crawler belt |
Synthetic rubber |
|
Climbing Capacity |
20° |
|
Ground pressure |
51kpa |
|
Hydraulic |
Hydraulic oil tank capacity |
80L |
Dimensions |
L*W*H |
2.85m*0.8m*1.45m |
