Wecan Diesel Forklift Truck 2.5Ton For Sale

Name: Wecan Diesel Forklift Truck 2.5Ton For Sale
Brand: WECAN
SKU: 140720820
Availability: InStock

US$ 1,000 - 200,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

WECAN

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name WECAN

Model Number CPCD25FR

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 2.5Ton

Max. Lifting Height 6000mm

Min. Lifting Height 3000mm

Fork Length 1070mm

Fork Width 100mm

Overall Dimensions 3605*1160*2095mm

Certification ISO9001

After-sales Service Provided Engineers available to service machinery overseas

Welcome to WECAN Forklift Truck CPCD25FR!

We are able to provide proffessional service and high quality products.

Looking forward to sincere cooperation.

Main features

2.5tons Diesel forklift turck 2 stage 3M Mast,

Hydraulic transmission(Automatic),1.07M fork,

China Engine 490BPG,Pneumatic tyre,

Seat with safety belt &steady bat Warning light.

Main technological parameters

Model		CPCD
		25FR
Load capacity kg		2500kg
Load center mm		500mm
Power type		Diesel
Max.lifting speeds(with load)mm/s		400mm/s
Max.Driving speeds(with without load) km/h		17/19km/h
Max.Towing speeds		15/10kN
(with/without load)kN
Gradeability(with/without load)%		15/20%
H1 Lifting height mm		3000mm
Free lift mm		60mm
Tilting angles(forward-backward) .		6/12
Min. turning radius mm		2450mm
Min. right angle aisle width mm		2050mm
Min. under-clearance mm		110mm
Dimensions	A Overall length(inincluding fork) mm	3605mm
	B Overall width mm	1160mm
	H Overall height(mast lowered) mm	2095mm
	H2 Overall height (mast extend) mm	4080mm
H3 Overall height to overhead guard mm		2095mm
A1 Fork overhang mm		451mm
A2 Wheel base mm		1640mm
Tread	B1 Front tread mm	970mm
	B2 Rear tread mm	970mm
Tyre	Front tyre	7.00-12
	Rear tyre	6.00-9
Total weight kg		3600kg
B3 Fork width mm		122mm
H4 Fork thickness mm		40mm
Backrest height mm
A3 Fork length mm		1070mm
Engine	Engine model	490
	Rate power KW	39KW
	Rotate Speed At Rate Power rpm	2650rpm
	Max.torque Nm	157Nm
	Rotate speed at max torque rpm	1980rpm
Type of power shift		Hydraulic

OPTIONAL ITEMS
ENGINE	EUROⅡ&Ⅲ CHIAN ENGINE, EURO Ⅲ JAPAN ENGINE
MAST	2-STAGE MAST 3.3M 2-STAGE MAST 3.5M 2-STAGE MAST 4M 2-STAGE MAST 4.5M 2-STAGE MAST 5M 3-STAGE MAST 4.5M 3-STAGE MAST 5M 3-STAGE MAST 5.5M 3-STAGE MAST 6M 3-STAGE MAST 7.3M
FORK	1220 MM FORKS 1370MM FORKS 1520 MM FORKS 1820 MM FORKS 2000 MM FORKS
TYRE	FRONT SOLID TYRES REAR SOLID TYRES DUAL SOLID FRONT WHEEL DUAL PNEUMATIC FRONT WHEEL
ADD CAB	CAB WITH FAN HEATER IN THE CAB
ATTACHMENT	FORK POSITIONER, FRONT-MOVING FORK, SIDE SHIFT, ETC.
OTHER ITEMS	FIRE EXTINGUISHER BOTTLE,FIREPROOF CAP ON THE MUFFLER, UP EXHAUST, ELECTRONIC SHIFT, GOOD DAMPING SEAT, ETC.
