1.6 Ton Micro Excavator , CE / ISO Certificate, CT16-9 D

Name: 1.6 Ton Micro Excavator , CE / ISO Certificate, CT16-9 D
Brand: Carter
SKU: 140719740
Availability: InStock

US$ 13,300 - 15,400 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Carter

Model Number:

Carter CT16-9BP

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Carter

Model Number Carter CT16-9BP

Condition New

Moving Type Crawler Excavator

Operating Weight 1700 Kg

Bucket capacity 0.04m3

Maximum Digging Height 3281mm

Maximum Digging Depth 2033mm

Machine Weight 1700 Kg

Max Digging Radius 3878mm

Rated Speed 2.7/5.0(km/h)

Certification CE ISO

After-sales Service Provided Overseas service center available

1.6 Ton Micro Excavator , CE / ISO Certificate, CT16-9 D

whatsApp/Tel:+86 18217056032

Engine		Travel System
Model	PERKINS-403D-11	Travel motors			Commer, Italy;
Type	Direct injection, water cooled, natural intake	Support roller quantities			2×3
		Carrier roller quantities			No
No. of cylinder	3	Travel shoes			No
Bore and stroke	77x81(mm)	Travel speed			2.7/5.0(km/h)
Displacement	1.131L	Drawbar pulling force			11.7kN
Power output	14.7kw/2200rpm	Grade ability			58%(300)
Max. torque	65N.m/2000rpm	Ground clearance			160mm
Hydraulic System		Cab & Electrical System
Pump	CASAPPA, Italy	Cab	All-weather, sound-suppressed Cab and equipped with a heavy, insulated Floor Mat,Front Window can be opened and slided; adjustable Seat
Type	Axial-piston pump+gear pump
Max. discharge flow	2x20.7+15.1(L/min)
Max. discharge pressure
Boom, arm and bucket	21 MPa	Voltage		12V
Travel circuit	12 MPa	Batteries		1X12V
Swing circuit	9 MPa	Battery capacity		60Ah
