Best brand Carter CT16-9BP Zero Tail Mini Excavator on sale

 Engine

      Travel System

Model

PERKINS-403D-11

Travel motors

Commer, Italy;

Type

Direct injection, water cooled, natural intake

Support roller quantities

2×3

Carrier roller quantities

No

No. of cylinder

3

Travel shoes

No

Bore and stroke

77x81(mm)

Travel speed

2.7/5.0(km/h)

Displacement

1.131L

Drawbar pulling force

11.7kN

Power output

14.7kw/2200rpm

Grade ability

58%(300)

Max. torque

65N.m/2000rpm

Ground clearance

160mm

       Hydraulic System

  Cab & Electrical System

Pump

CASAPPA, Italy

Cab

All-weather, sound-suppressed Cab and equipped with a heavy, insulated Floor Mat,Front Window can be opened and slided; adjustable Seat

Type

Axial-piston pump+gear pump

Max. discharge flow

2x20.7+15.1(L/min)

Max. discharge pressure

Boom, arm and bucket

21 MPa

Voltage

12V

Travel circuit

12 MPa

Batteries

1X12V

Swing circuit

9 MPa

Battery capacity

60Ah
