Hyundai 30 Ton Excavator R305LC-9

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
Hyundai 30 Ton Excavator R305LC-9 thumbnail-1
Hyundai 30 Ton Excavator R305LC-9 photo-1
US$ 50,000 - 140,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Hyundai
Model Number:
R305LC-9
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Hyundai
Model Number R305LC-9
Condition New
Moving Type Crawler Excavator
Operating Weight 29700KG
Bucket capacity 1.38m3
Maximum Digging Height 10160mm
Maximum Digging Depth 7500mm
Machine Weight 29700KG
Max Digging Radius 4230mm
Rated Speed ~
Certification ISO90001-2008
After-sales Service Provided Engineers available to service machinery overseas

Hyundai 30 ton excavator R305LC-9
big excavators
large excavator price
cheap large Excavator
Excavators hyundai brand





Weight: 30200kg



Bucket:1.38m3







Engine:



Model:  C8.3-C



Rated Power:196/1900KW/rpm



Max torque:124.3/1300kgf.m/rpm







Hydraulic systme:



Working pressure:350kgf/cm2



Max. flow:2*252L/min







Performance



Swing Speed:10.2 rpm



Travel Speed:5.2/3.1 km/h



Max.digging force(bucket)             19600kgf



Max.digging force(jib)                 13900kgf



Grade Ability:                         35degree



Max. Traction                         27300kgf







Specification:



A-Crawler Length:                                           4940mm



B-Crawler ground length:                                 4030mm



C-Stick length:                                           2600mm



D-Track shoe width:                                         600mm



E-Min.ground clearance:                                    500mm







Oil Tank :                 500L



Hydraulic tank:             190L







Dimensions



F-Total length:                                                  10560mm



G-Overall width:                                                3200mm



H- Total height:                                                 3300mm



I- Counter weight ground clearance:                 1190 mm



J- Tail length                             3260mm



K-Up width                               2980mm



Hyundai 30 ton excavator R305LC-9

































































Hyundai 30 ton excavator R305LC-9







































































Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9Hyundai 30 ton excavator R305LC-9
