3 axles lowbed semi trailer

Vehicle

Vehicle Name

3 axle low bed semi-trailer

Vehicle Model

9401TDP

Loading capacity

40T

Dimension Parameter

Overall length (mm)

13000

Overall width (mm)

3000

Overall height (mm)

2015

Wheelbase (mm)

8580+1310+1310

Front / rear suspension (mm)

-/1400

Front / rear tread (mm)

-/2180/2180/2180

Weight Parameter

GVW (kg)

40000

Payload weight (kg)

30000

Kerb weight (kg)

10000

Others

Spring leaf No.

-/8/8/8

Tyre type

8.25R20

Tyre No.

12

Suspension

3 axle mechanism suspension

Axle

3* 13T FUWA

Landing gear

Jost 28T, two-speed, manual operation

Material of main beam

16Mn

Main beam

Height: 500mm, top flange: 20mm, bottom flange:20mm, middle flange: 10mm

Platform plate

6mm diamond plate

Kingpin size

2” or 3.5”

Electrical

24V, 7 pin socket

Equipment

Double tyre carrier, one tool box

Painting

Sand blasting before painting, one coat of primer, anti-corrosion, two coat of finish painting, color can be choose as client request.
