14 Tons Changlin Vibratory Road Roller YZ14-3 Weight of Road for Sale

Name: 14 Tons Changlin Vibratory Road Roller YZ14-3 Weight of Road for Sale
Brand: Changlin
SKU: 140717868
Availability: InStock

US$ 10,000 - 31,600 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Single Drum Roller

Travel Speed:

0-4km/h

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Single Drum Roller

Travel Speed 0-4km/h

Grade Ability 30%

Brand Name Changlin

Model Number YZ20J

Power(W) 128kw

Dimension(L*W*H) 6328*2460*3285mm

Weight 20000kg

Certification ISO9001

After-sales Service Provided Engineers available to service machinery overseas

14 Tons Changlin Vibratory Road Roller YZ14-3 weight of road for sale

whatsApp/Tel:+86 18217056032

Overall Dimension
1	Length	6328mm
2	Width(to outside of wheels)	2460mm
3	Height(To the top of the cab)	3285mm
4	Wheel base	3151mm
5	Tread	1645mm
6	Min. ground clearance	432mm
Main Technical Specification
1	Static line force	474N/cm
2	Dynamic line force	1659 N/cm
3	Operating weight	20001kg
4	Nominal Amplitude high low	1.9mm 1.0mm
5	Centrifugal-Force high low	353kN 270kN
6	Total stress force	46360(kg)
7	Static Weight at Drum	10000kg
8	Static Weight at Tires	10000kg
9	Frequency	29/35Hz
10	Min. turning radius(Outside of rear wheel)	6800mm
11	Drum diameter	1600mm
12	Drum width	2130mm
13	Drum thickness	40mm
