SR285RC8 drilling rig animation
- 100 Set / Sets per Month
- shanghai/qingdao
- T/T D/P D/A Credit Card
- High performance sr380 water well rotary drilling rig for sale
- Good performance drilling water wells sr380 made in china
- Hot sale rotary drilling series and drilling water wells
- SR380 rotary drill machine rotary drilling series
- 145ton Easy Operating sr380 rig machine
- Hot recommend drilling and exploration/rig machine
Product Details
Condition: | New | Type: | Rotary Drilling Rig | Power Type: | Diesel |
Place of Origin: | Shanghai, China | Brand Name: | sany | Model Number: | SR285RC8 |
Usage: | Coal | Weight: | 98000KG | Certification: | GOST CE ISO9001 |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Nude package roro
Product Description
SR285RC8 drilling rig animation
Feature of SR285RC8 drilling rig animation
· New industrial design;
· The fifth generation of rotary drive;
· New generation of professional chassis;
· Rock drilling and anti-shock technology;
· Hydraulic system with excellent shock resistance ability;
· Drilling tools for super-hard rock;
· Multifunctional;
· S-ADMS control system
Paraments of SR285RC8 drilling rig animation
Main performances | Unit | Parameters |
Drlling | ||
Max.drilling diameter | mm | 2300 |
Max.drilling depth(friction/locking) | m | 88/57 |
Rotary Drive | ||
Max. torque | kN.m | 285 |
Speed of rotation | rpm | 5-24 |
Crowd system | ||
Crowd force | kN | 260 |
Line pull | kN | 260 |
Stroke | mm | 6000 |
Main winch | ||
Line pull(1st layer) | kN | 315 |
Rope diameter | mm | 36 |
Max. line speed | m/min | 60 |
Auxiliary winch | ||
Line pull(1st layer) | kN | 90 |
Rope diameter | mm | 20 |
Max. line speed | m/min | 70 |
Mast inclination | ||
Forward | ° | 5 |
Lateral | ° | ±4 |
Base machine | ||
Overall height | mm | 24425 |
Operating weight | kg | 98000 |
Company Profile
Shanghai Evangel Industrial Co., Ltd. is a leading Chinese construction machinery exporter, affiliated with Evangel International Machinery Limited, located in the downtown of Shanghai City. Since our company was founded, based on the advantage of XCMG which is the No.1 Chinese construction machinery manufacturer, we continually introduce Chinese excellent construction machinery enterprises and their products to international markets, such as SANY, ZOOMLION, CHANGLIN, LIUGONG, SDLG, HOWO, SHANTUI, HBXG, YTO, BEIBEN etc. We not only make more international customers know and approbate our products, but also gradually build up friendship with construction machinery customers all over the world.
Our Strengths are as follows:
(i) Eight years professional experience in international trading and rich knowledge in construction machinery & heavy equipment industry, which enable us to turn customer inquiries into final products and export them to numerous countries and regions without barriers;
(ii) A well educated and friendly sales team with international vision, members of which can speak fluent multiple languages, such as English, Spanish, Portuguese, Russian, Arabic and French etc;
(iii) Strong long term dealership from various top manufacturers, assuring that all our products are original brand new ones with competitive price;
(iv) Excellent logistics services (by sea, air, railway or road), ensuring timely delivery of consignments all over the world;
(v) Comprehensive after-sales service, including one year warranty, spare parts supply, installment and maintenance, and training;
(vi) An expertly managed ERP system and a well coordinated quality control system to satisfy various client requirements.
EVANGEL has passed the international quality management system of ISO9000, CE, SGS, UL and other products certification. We have an excellent after-sales service system in the interests of customers to establish good strategic partnerships with agencies around the world. We won the good reputation from reliable quality, competitive price and excellent after-sales service. Our export revenue increases constantly every year, and our products have already entered nearly 100 countries across the continents of South America, Africa, Middle East, Australia, Russia, Middle Asia, South Asia, Southeast Asia, and East Europe. We sincerely hope to cooperate, develop together and build a good future with you.
EVANGEL, your best choice for construction machinery in China!
