High/Low carbon steel/ straight line Wire drawing machine
- 10 Set / Sets per Month
- Tianjin-xiangang
- T/T Credit Card
-
4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
-
DOING supply photovoltaic solar panels recycling machine
-
four-axis welding machine for commercial sink panel and bowl
-
Double Platform Stainless Steel Kitchen Equipment Polishing Machine
-
Photovoltaic solar panels recycling plant
-
Solar panel recycling machine with high efficiency
Product Details
| Place of Origin: | Hebei, China | Brand Name: | CY | Model Number: | WDM-0211 |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Automatic 6.5mm-2.0mm Steel Iron Wire Drawing Machine China Supplier
Main Specification
Type | LW-1/800 | LW-1-6/560 | LW-1-7/450 | LW-1-6/350 |
Material intensity |
| δb≥110kg/mm2 | 128kg/mm2 | δb≥140kg/mm2 |
Max diam of material | 10-14 | 6.5mm | 3.4mm | 2.5mm |
Min diam of material | 6.0 | 2mm | 1mm | 0.75mm |
Diam of block | 1-800 | 1-6/560 | 1-7/450 | 1-6/350 |
Max average condensation | 25% | 30% | 20% | 21% |
Total condensation |
| 78-88.5% | 77.9% | 78% |
Max.speed of block | 60m/min | 245m/min | 346.9m/min | 200m/min |
Total power | 80kw | 18.5-30kw | 7.5-11kw | 7.5-11kw |
Weight | 4500kg | 2000kg | 1500kg | 1000kg |
Overal size | 9730×3340×2020mm | 1700×1150×1750mm | 1520×810×1700mm | 1400×800×1500mm |
Main Featrues
1.Precise design, easy operation.
2.High speed and stability fitting your goal of efficiency.
3.Made from high quality material, undergoing high abrasion-resistance and low deformation heat treatment process, the machine is endurable with long time preciseness.
4.The forced feed lubricator guarantees oil-film lubrication of the rubbing parts and ensures the lasting use of the machine.
wire drawing machines can be ordered according customer's request
Machine to be installed and commissioned by SM technicians.
The seller will send our engineer to install the machine accordingly if the buyer need.
The buyer have to pay the salary US$100 per day, and the air ticket, accommodation, eating and some related fees should be your responsibility.
It is in same condition if the buyer need the seller to send the interpreter.
