high speed water tank type wire drawing machine made in chain (ISO CE)
- 20 Set / Sets per Month
- Tianjin
- T/T L/C Credit Card PayPal
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- DOING supply photovoltaic solar panels recycling machine
- four-axis welding machine for commercial sink panel and bowl
- Double Platform Stainless Steel Kitchen Equipment Polishing Machine
- Photovoltaic solar panels recycling plant
- Solar panel recycling machine with high efficiency
Product Details
Place of Origin: | Hebei, China | Brand Name: | HTK | Model Number: | HTK-550 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Wire Drawing Machine Price (Water Tank Type)/Steel Wire Making Machine
The water tank wire drawing machine is used to draw the low carbon, medium carbon, high carbon wire, etc.
Technical parameter:
Type | LT2-17/280 | LT1-11/350 | LT1-9/450 | LT1-12/350 | LT1-9/560 |
Drum diameter | 280mm | 350mm | 450mm | 350mm | 560mm |
Number of mould | 17pcs | 11pcs | 9pcs | 12pcs | 9pcs |
Input diameter | 2.5-2.0mm | 2.8-2.5mm | 3.4-3mm | 2.2mm | 4.7mm |
Output diameter | 0.9-0.45mm | 1.4-1.2mm | 1.8-1.6mm | 0.7mm | 1.6mm |
Speed (m/min) | 500-650 | 160-350 | 160-300 | 250-400 | 280-300 |
Motor | 22-30kw | 30-45kw | 37-45kw | 15-18.5kw | 110kw |
Dimension (mm) | 3000*1300*1100 | 2400*1400*1200 | 3000*1500*1200 | 2400*1100*1100 | 3500*1500*1200 |
Weight | 4200kg | 3300kg | 4000kg | 1800kg | 4000kg |
One 20ft container/Set
Package: Stretch Film or Pallet
Main Farm Fence Wire Machinery: 1 Unit
Coil Holder: Several Units
Tool Cabinet: 1 Unit
Spare Parts: Several Units
Payment:30% TT for advance payment, 70% TT after the copy of B/L.
1.Farm Fence Wire Machinery Warranty: One Year.
2.Enough spare parts of machines could be supplied.
3.All machines were tested and adjusted before delivery.
4.Engineers available to service machinery overseas: Worker-training, installation.etc.
5.24 hours technical support by e-mail or calling service.
Our Factory:HEBEI HTK WELDING EQUIPMENT CO.,LTD.
We have 3 senior engineers,105senior technicians, more than 100 employees
- Our products: Field Fence and Farm Fence Wire Machine, Welded Wire Mesh Machine
- Our certifications: ISO 9001:2000, BV certification
- Our Main Market:South Africa, Mongolia, Asia, Dubai
Advantage of HTK Factory:
- We have professional engineer supervision
- The price preferential benefit
- Product quality assurance
- High production efficiency
- With credibility and protection
- Can visit the factory in person
- Good after sales service
- Business model: Factory direct
MOQ: 1 Set Farm Fence Wire Machinery.
Welcome to visit 15 years old factory!!!
