Home > Products > Welded Wire Mesh Panel Machine > Hebei HTK galvanizing wire mesh welding machine
Hebei HTK galvanizing wire mesh welding machine
- 2 Set / Sets per Month
- XINGANG CHINA
- T/T Credit Card PayPal
Product Details
Place of Origin: | Hebei, China | Brand Name: | HTK | Model Number: | DNW-5 |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Hebei HTK galvanizing wire mesh welding machine
- PLC system control
- Direct factory
- Solid joints, no burning marks
- Simple and easy to operate
Characters:
- Strong welded points and bright luster .
- The mesh doesnt come loose even if cut in parts or being exerted force on parts .
- Compared with general iron wire ,the products are better in respects of anti-corrosive and anti-rust
Technical Parameter:
Items | DNW-1 | DNW-3 | DNW-4 | DNW-4-1 | DNW-4-2 |
Welding width | 1200mm | 1600mm | 2500mm | 2500mm | 2000mm |
Weft Spacing | 50-200mm | 50-200mm | 25-200mm | 25-200mm | 50-300mm |
Warp Spacing | 50-200mm | 50-200mm | 50-300mm | 50-300mm | 50-300mm |
Wire dia | 1.4-2.3mm | 2.8-4.5mm | 2.8-5.0mm | 3.0-6.0mm | 5.0-8.0mm |
Welding speed | 55times/min | 45times/min | 30times/min | 30times/min | 40times/min |
Rated Power | 50KVA x 2 | 120KVA x 4 | 160KVA x 4 | 180KVA x 6 | 200KVA x5 |
Rated voltage | 380V | 380V | 380V | 380V | 380V |
Overall dimension | 2.4 x2.4 x1.4 | 2.2 x 2.4x 1.8 | 3.1x 8x 1.9 | 3.1x 8x 1.8 | 2.6 x 7x 1.8 |
Fence Machine | Full Automatic Hinge Joint Fence Machine |
Full Automatic Fixed Knot Fence Machine | |
Welded wire mesh machine | Automatic welded wire mesh machine |
Welded wire mesh panel machine | |
Breed aquatics row welded wire mesh machine | |
Numerical control welding fence row machine | |
Barbed wire machine | Barbed wire machine |
Razor barbed wire machine | |
Diamond mesh machine | Full Automatic Chain link wire mesh machine |
Hexagonal wire mesh machine/Gabion Mesh machine | |
Crimped wire mesh machine | Automatic crimped wire mesh machine |
Beautiful grid crimped mesh machine | |
Other machines | grassland mesh machine |
Reinforcing mesh welding machine | |
Wire Nail Making machine | |
Expanded metal machine | |
Wire drawing machine |
Packaging: in pallets, in plastic film or as per customers’ requirements.
Shipping: within 25days after receiving the prepayment or relevant L/C.
Guarantee and After-sale Service:
1.Warranty: One Year.
2.Enough spare parts of machines could be supplied.
3.All machines were tested and adjusted before delivery.
4.Engineers avaliable to service machinery overseas:Worker-training, installation.etc.
5.24 hours technical support by e-mail or calling service.
Our Factory:
Hebei HTK Welding Equipment Manufacture Co., Ltd
We have 2 senior engineers,10 senior technicians, more than 100 employees
- Our products: Field Fence and Field Fence Machine, Welded Wire Mesh Machine
- Our certifications: ISO 9001:2000, BV certification
- Our Main Market: South Africa, Mongolia, Asia, Dubai
Advantage of HTK factory:
- We have professional engineer supervision
- The price preferential benefit
- Product quality assurance
- High production efficiency
- With credibility and protection
- Can visit the factory in person
- Good after sales service
- Business model: Factory direct
Payment: 30%TT in advance and pay off the balance against the copy of B/L.
MOQ: 1 Set.
Welcome to visit 15 years old factory!!!
