Specifications
infrared thermometer IR thermometer purple&white :1.Operating Temperature 10 to 40 degree .
2.Body Infrared Thermometer
1 General Description
Non-contact Body Infrared Thermometer is Specially designed fo take the body temperature
of a person regardless of room temperature.
Depending on various skin types and thickness, there may be temperature difference.
When the indoor temperature is significant difference, the body infrared thermometer should
be placedt in that room for 15 to 20 minutes before using.
2 Safety Information
•This device must only be used for the purposes described in this instruction manual.
•This device must only be used in an ambient temperature range between 10 and 40 .
•Do not expose this thermometer to extreme temperature conditions of >40°C or <0°C
•Do not expose this thermometer to electric shocks.
•Do not use the device in relative humidity higher than 85%RH
•Do not use the device near large electromagnetic fields such as found with cordless or cell
phones.
•Keep the device away from water and heat, including direct sunlight,
•Do not drop or knock the device ,and dot not use if damaged
•It may affect the accuracy of measurements when the forehead is covered by hair
perspiration, cap or scarf.
•Keep the measuring distance as <5cm(<2in)
•When the body infrared thermometer should be left in that room during 15to 20 minutes
before using.
•It may affect the accuracy of measurements when the forehead is covered by perspiration
or other factors, please take the temperature behind the ear lobe.
•Clean the glass with cotton bud lightly moistened with 70% alcohol.
°C °C3 Features
•Precise non-contact measurements
•Built-in laser pointer
•User selectable °Cor°F
•Automatic selection range and Display Resolution 0.1°C(0.1°F)
•Automatic Data Hold & Auto Power off
•Set Alarm value(the alarm threshold default value is 380°C(100.4°F)
•Backlight LCD Display
•Memorization of the last 32 measurements
4 Intended Use
•The Non-contact Body Infrared Thermometer is designed for body surface and forehead
temperature measurement for infants and adult s without contacting to human body. It can be
used by consumers in household environment in accordance with the ASTM 1965-1988
•Standard specification for Infrared Thermometers for Intermittent Determination of Patient
Temperature.
5 Precaution Before Use
•In order to obtain reliable and stable results, when changing the environment to a room
with a significant temperature difference, it is recommended to leave the Non- contact Body
Infrared Thermometer to this ambient temperature for 15 to 20 minutes before using it.
•Depending on various skin types and thickness, there may be temperature difference.
•Do not expose the thermometer to sunlight or to water.
•Allow one minute interval between two measurement.
Normal Conditions of Use
Measuring Range
Non-contact Body Infrared Thermometer Precision
Display Resolution 0.1°C(0.1°F)
Operating Temperature 10 to 40°C(50 to 104°F)
Humidity Rate ≤85%
Power 9V(NEDA 1604A or IEC 6LR61)
Size 88 x 42 x 175 mm(L x W x H)
Weight 122g(Without batteries)
Measuring Range 32.0 to 43.0°C(90 to 109.4°F)
Accuracy ±0.3°C(0.54°F )
Measuring Distance 5cm(2 in)
Automatic Stop 7 sec.
32 to 39.5°C/93.2 to 96.6°F ±0.3°C/0.5°F According to ASTM
36 to 39°C/96.8 to102.2°F ±0.2°C/0.4°F Standard E1965-1998(2003)
39to42.5/102.2to108.5°F ±0.3°C/0.5°F
