USB 2.0 to rj45 cables USB Lan rj45 ethernet 10/100 mbps network adapter For Apple Mac MacBook Air Andriod Tablet Laptop PC

Specifications

Lan rj45 ethernet 10/100 mbps network adapter
1.usb rj45 cables
2.For Apple Mac MacBook Air Andriod Tablet

usb2.0 10/100 Mbps ethernet lan network RJ45 adapter For Apple Mac MacBook Air Andriod Tablet Laptop PC

Features   (usb lan rj45 ethernet 10/100 mbps network adapter)
Supports 10/100 Mbps auto-sensing capability
USB specification 1.0,1.1 and 2.0 compliant
Suppores USB full and high speed modes with bus power capability
IEEE802.3,802.3u (10Base-T 100Base-TX) compatible
Supports both full-duplex and half-duplex operation on Fast Ethernet
Plug & play installation



USB 2.0 to RJ45 Lan Ethernet Network Adapter For Apple Mac

Description:  (usb lan rj45 ethernet 10/100 mbps network adapter)

Condition: 100% Brand new
.USB2.0 to Ethernet Lan RJ45 Network card.

.Input: USB
Output: RJ45
USB2.0 standard, compliant to USB1.0, 1.1
Supports 10Mbps or 100Mbps network automatically
Supports IEEE802.3X FLOW CONTROL FOR Full Duplex mode
Enable to connect to the internet via the USB port
Powered by USB port, no external power adapter required

System Requirements:  (usb lan rj45 ethernet 10/100 mbps network adapter)
Windows98SE/2000/ME/XP XP/Vista/
Mac OS 10.4

Package Included:

1 x USB 2.0 RJ45 adapter















1.Before order service:

we will be kindly reply your inquiry in quickest way

2.Order

we can offer OEM/ODM ,customized for you

3.After sales service:

Most products is 1 years warranty





USBONLINE INT'L ELECTRONICS LIMITED is a high-tech enterprise with more than 10 years' experience of R&D, production, marketing and sales. We are specializing in the production of electronic products

Such as network/laptop/computer accessories,we can offer rj45 ethernet cable(shielded one) network cable adapter/usb to rj45 cable adapter/rj45 to rj11 adapter/copper wire cable/network cable tester/lan network cable/b cable tester/rj45 rj11 crimping tools

We can also offer hdmi/for iphone cables accessories.

1.What's the difference between Cat 5, Cat 5e and Cat 6 Network Cables? Can I use one in place of another?

----The difference is in the bandwith ratings. Cat 5e has a higher bandwidth than Cat 5. Cat 6 has a higher rating than Cat 5e. They all use RJ45 connectors and are usually interchangeable depending on the bandwidth requirements of your devices.

(bandwith ratings:cat6>cat5e<cat5)

2.What is the difference between shieled networking cable and not shield one rj45 cables?

----STP cable will more safe for transfer data,but it will be not easy to install,and for UTP one will be easy to install

3.What is an RJ45 cables/cord?

----An RJ45 connector is a registered jack connector used as a wiring pattern for high-speed modem connection to a telephone network. The connection uses a keyed connector known as 8P8C modular connector.

in short,it is an eight wire connector used commonly computers

4. What is an RJ45 Patch Cable?

---- RJ-45, or RJ45, is an eight-pin connector that is most commonly seen in use on network cables such as the cable that connects your PC to a router. This connector is a little larger than the RJ 11 connector,

which is normally seen connecting your telephone to your wall outlet. There are different types of RJ-45 connectors, all based upon the type of cable used. Telephone, Category 5e(cat5e), Category 6(cat6), and 10 Gbit cables with either solid conductors or stranded conductors, all use RJ-45 connectors. Some cables are designated as "crossover" cables, which have a different pin configuration than a standard patch cable.

5.What is Cat5e( Category 5e )

----CAT 5e patch cables use UTP cables or foil-shielded twisted pair (FTP) cables.

This RJ-45/CAT 5e patch cable is the most basic patch cable used to move Ethernet data signals between devices such as your home PC to your home network router.

There are two standard wiring pin configurations used for connecting the individual wires within the UTP cable to each of the eight-pin connectors inside the RJ-45 connector.

There is a standard called 568-B Wiring in a similar standard called 568-A Wiring. The 568-B Wiring standard is the most common standard used for patch cables. In this patch cable, 10BaseT Ethernet uses pairs

6.What is Cat6( Category 6 )

----CAT 6 patch cables are physically identical to CAT5 patch cables with the only difference being that the electrical characteristics of the RJ-45 connector and the UTP or FTP cables conform to the EIA/TIA 568-B2.2-1 category 6 specification.

This specification calls for specific performance levels in terms of bandwidth and data transfer speed. Data traveling through a network is only as fast as the slowest component in the network.

If your network is configured to operate at CAT 6 speeds and bandwidth, you must use a CAT 6 patch cable as opposed to a CAT 5e patch cable to maintain the data bandwidth and speed in the network.
