Specifications
The flange type spray nozzle can be custom made, serveral kinds of wear resistant material are available.
Design Feature
This kind of hollow cone flange type spray nozzle is fixed on the fiberglass reinforced Polyester flange, to which there is a silicon carbide cuspidal structure connected by ligation. Other material is optional upon your request. There available connection size of flange can be 2", 3" and 4". The flow rate range is from 535 L/min to 2000 L/min under pressure of 0.7 bar. Spray angle is from 60 degree to 180 degree for 2", while 60° To 120° For 3" and 4".
These high flow rate spray nozzles play a important role in pollution control, cooling and air infalting. Because of its large and free flow channel, it is seldom clogged.
This kind of spray nozzle have precise deflect blade to produce uniform distribution and the excellent coverage area. The flange type spray nozzle can be custom made, serveral kinds of wear resistant material are available.
COMMON APPLICATION
Flue gas desulfurization
Dust removing
Gas cooling
1.packaging :standard export package,carton package.
2.shipping: air delivery or express company.
3.delivery time:5-10days.
1.OEM and ODM service
2.import and export agent.
duct design and manufacture
duct technical guidance;
JTC Spraying & Purification Technology Co., Ltd. is located in Keyuan, Tangxia Town, Dongguan City. Our company covers an area of more than 30000 square meters for research & development, manufacture, and office and site construction.
Our company manufacturing spray nozzles and air filters. Our company follows strict quality standards. We passed ISO9001 International Quality Management System Certification in 2003 and have been carrying out quality control strictly according to the requirements of this syste...
JTC Spraying & Purification Technology Co., Ltd. is located in Keyuan , TangxiaTown, Dongguan City. Our company covers an area of more than 30000 square meters for research & development, manufacture, and office and site construction.
Our company manufacturing spray nozzles and air filters. Our company follows strict quality standards. We passed ISO9001 International Quality Management System Certification in 2003 and have been carrying out quality control strictly according to the requirements of this system. In addition, we attained ISO14001 Certification in 2004.
Our spray nozzles include fog nozzles, fog misting nozzles, impingement misting nozzles, air atomizing nozzles, spiral nozzles, flat fan spray nozzles, solid cone spray nozzles, hollow cone spray nozzles/full cone spray nozzles, flood jet nozzles, high pressure nozzles, tank washing nozzles, silicone carbide nozzles, sand blasting nozzles, filter nozzles, plastic adjustable ball (clamp) nozzles, clip eyelet nozzles, wind jet nozzles, mixing educators, plastic nozzles, PP nozzles, Teflon nozzles, PVC nozzles, PVCF nozzles, ABS nozzles, and ceramic nozzles. Our products are applied in many industries.
Our products are extensively used in local market and are exported to the UK, the USA, Canada, Korea, Italy, Thailand, Japan, Singapore, India, Pakistan, Russia and other countries and regions.
We are able to design and manufacture any spray nozzles you want.
We provide all our products with the highest quality, the lowest prices, the fastest delivery and the best service for all customers.
