Soft Wall Clean RoomModular construction, easy to increase clean level,
customerized design is welcomed
Soft Wall Clean Room
Introduction:
Soft Wall Clean Room is an air purifying equipment which can provide purified air with high cleanliness for partial area.
Application:
Soft Wall Clean Room is suit for workshop high cleanliness is required in some area, such as assembly line, high precision products assembly area.
Feature:
1. Assembly type structure, easy to assemble, shorten the delivery time;
2. Easy to move(with wheel); suit for small clean area;
3. Modular structure, easy to increase the cleanliness class;
4. Compared with laminar air flow bench, the working area in clean booth is larger; compared with traditional clean room, it is with low cost, short construction period.
Structure:
The frame of soft wall clean room is made from industrial aluminum profile, and the air is supplied by FFU, the frame is coved with anti-static curtain or organic glass, the top of clean booth is sealed with blind plate. The cleanliness class can vary from 10 to 100,000.
Material:
1. Frame: stainless steel or Aluminum, firm, nice, anti-rust, dust-free;
2. Anti-static curtain: 0.5mm,good effect of anti-static; transparent, soft, not easy to deform or age; thermal insulation;
3. Anti-static organic glass: good effect of anti-static, transparent, not easy to deform or age;
4. The cover plate and blind plate are made from 1.2mm cold plate spray;
5. Clean lighting system is at customer’s option;
6. FFU: low noise centrifugal-type motor, long life time, low noise, maintenance-free, small vibration, speed adjustable, HEPA filter is with small initial pressure drop, large dust holding capacity.
We can customize the soft wall clean room based on your requirement.
Model |
BKCB-1500 |
BKCB-2000 |
BKCB-3000 |
BKCB-5000 |
External Size (W*D*H) mm |
1500*2000*2500 |
2000*3000*2500 |
3000*4000*2500 |
5000*5000*2500 |
HEPA Filters |
99.999% efficiency at 0.3 um |
|||
Consumption |
500W |
800W |
1000W |
1600W |
Weight |
350kg |
420kg |
570kg |
820kg |
FFU Nos. |
4 pcs |
6 pcs |
12 pcs |
25 pcs |
Clean Level |
ISO 5 (Class 100), Class A |
|||
Control System |
Microprocessor control system |
|||
Rectangular Tube Material |
Stainless steel/ aluminum/ painting steel sheet |
|||
Wall Material |
Anti-static dustproof curtain |
|||
Blower |
Built-in centrifugal blower; speed adjustable |
|||
UV Lamp |
Emission of 253.7nm, with UV timer |
|||
Air Velocity |
0.1~0.6m/s, average 0.45m/s |
|||
Noise |
≤58db |
|||
Power Supply |
110/220V±10%, 50/60HZ |
|||
Customized design for clean level, size or material is available | ||||
