Home > Products > Stainless steel pumps > Food Grade Stainless Steel Milk Self Priming Pumps
Food Grade Stainless Steel Milk Self Priming Pumps
US$ 200 - 2,500
/ Piece
1 Piece(Min. Order)
- Ningbo or Shanghai Port
- T/T Money Gram Credit Card PayPal
You May Like
-
China Hot Steel Industrial High Viscosity Screw Pump for Food
-
Stainless Steel Self Priming Water Pump
-
Stainless Steel 2.2KW Self Suctioning Pump
-
Food Grade Stainless Steel Self Suction Pump
-
CE Confirm Stainless Steel High Viscosity Double Screw Pump for Pulp of Fruit
-
Industrial Steel Mono Screw Hot Oil Pumps With Pressure for Sale
Product Details
| Place of Origin | Zhejiang, China | Brand Name | l&b | |
| Model Number | FZB | Theory | Jet Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Other, Electric, 5.5-11KW | Standard or Nonstandard | Standard | |
| Fuel | Gasoline | Pressure | Low Pressure | |
| Application | Other, liquid, Food, juice, milk, etc |
Product Description
Product Description
Self-priming pump adopts acid-resisting stainless steel (AISI 316)in value body ,which has unique acid and alkali resistance , and comply with sanitary requirements for foods.
As a positive displacement pump, its features are superior to centrifugal pump since it suction liquid mixed with air or foams and even merely air. It is widely used to suction material with liquid level below the pump, for instance in the milking room, it suctions milk from the milk barrel. It can also be used in automatic CIP cleaning system as return flow pump in cleaning tank. The mechanical sealing is the build –in influx type ,and the temperature of suctioned material is no higher than 100°C.
Technical Parameters
| Model | 20 T/24 M | 30 T/24 M | 40 T/36 M |
| Flow | 20 T | 30 T | 40 T |
| Total Head | 24 m | 24 m | 36 m |
| Suction Stroke | 5-6 m | 5-6 m | 5-6 m |
| Impeller Diameter | 192 mm | 192 mm | 215 mm |
| Inlet/Outlet Diameter | 63.5/63.5 mm | 76.5/63.5 mm | 76/76 mm |
| Motor Type | M2QA132S4A | M2QA132M4A | M2QA160SM4A |
| Power | 5.5kw(380V/50HZ ) | 7.5kw(380V/50HZ ) | 11kw(380V/50HZ ) |
| Speed | 1420 r/min | 1420 r/min | 1420 r/min |
| Dimensions(L*W*H) | 760*320*475 | 760*320*475 | 1006*360*600 |
| Machine Weight | 110 kg | 116kg | 168kg |
Product Picture
