Sanitary Stainless Steel Milk Fermentation Tank, Beer Fermenter(BLS)

Sanitary Stainless Steel Milk Fermentation Tank, Beer Fermenter(BLS) thumbnail-1
Sanitary Stainless Steel Milk Fermentation Tank, Beer Fermenter(BLS) thumbnail-2
Sanitary Stainless Steel Milk Fermentation Tank, Beer Fermenter(BLS) photo-1
Sanitary Stainless Steel Milk Fermentation Tank, Beer Fermenter(BLS) photo-2
US$ 500 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Capacity:
100-30000L
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Zhejiang L And B Fluid Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Capacity 100-30000L
Place of Origin Zhejiang, China
Brand Name BLS
Model Number 0.2-20T
Dimension(L*W*H) As per your requirment
Weight according to the model
Certification CE, SGS etc.
Warranty 1 year
After-sales Service Provided No overseas service provided



Sanitary  stainless steel milk fermentation tank,  beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)



Structure characteristics:

  1. Made of double layers  or three layers
  2. Materials : sanitary stainless steel,304 or 316
  3. Humanized structure design and easy to operate.
  4. Inner wall fineness: less than 0.6um
  5. Conical bottom design

Configuration of tank:

  1. Volume from 100L-30000L,could be customized
  2. Various types of CIP cleaners.
  3. Inner body,Jacket, and isolation.
  4. Adjustable   bracket
  5. Cooling jacket adopt dimple jacket,arched and corrugated access jacket
  6. All pipes are ISO or DIN sanitary pipe
  7. Dismountable materials input pipe assembly.
  8. Thermometer (According to customer requirements).
  9. Ladder (According to customer requirements).
  10. Liquid level meter and level controller (According to customer requirements )

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

  Parameters/ Model   FJ0.1   FJ0.2   FJ0.5 FJ1    FJ2   FJ5   FJ10 FJ20  FJ50
  (L)  Volume   100   200   500   1000   2000   5000   10000 20000  50000
  (mm)  Diameterof  fermentation  tank   400 500  700  900    1200 1500  1800    2300 3100
  (mm)  Height  of  fermentation  tank   2000 2300    2650   2900   3800 4480    5250 6550  8550
  (Mpa)  Pressure  in  tank   0.2   0.2   0.2   0.2   0.2   0.2   0.2   0.2   0.2
  (Mpa)  Pressure  in  jacket   0.3   0.3   0.3   0.2   0.3   0.3   pipe0.3 pipe0.3  pipe0.3
    Umber  of  blending  paddles     2     2     2      2      2      3        3        4  4
  (r/min)  Blending  rotation   400 360 265    220 180  160    145 125  110
  (KW)Motor  power   0.55 0.75  1.1   1.5 3    5.5 7.5  7.5  11
  Cooling  mode   Jacket   Jacket   Jacket   Jacket   Jacket   Jacket   Equipment with lined heat exchanger   Equipment with lined heat exchanger   Equipment with lined heat exchanger

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

 Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)

Sanitary stainless steel milk fermentation tank, beer fermenter(BLS)



Please contact our After-sales service department in time within 30days after you received the cargo.
Tel: 0086-18815023521              Time: 9:00 a.m.- 6:00 p.m. (Beijing time)
 Process  Please provide the copy of Sales Contract and describe the problems appeared.
Problems confrimation:
Slight problem:  Please send the proof to our After-Sales Department, we will reply within two days.
Serious problem:
a We will dispatch our Quality and Problems Appraisers to make a confirmation.
b Have a negotiation of the compensation and sign agreements
c Our After-Sales Department will perform the duties as the agreements



We are specialized in producing different kinds of valves, pipe fittings tubes, manhole covers, pumps and tank so on for many years. We can design the products according to your special request. OEM is welcomed too.
