Stainless Steel Magnetic Stirrer
US$ 800 - 3,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Agitator
Product Type:
Fertilizer
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Suppliers Top Quality Stainless Steel Tube Heat ExchangerUS$ 1,500 - 12,000MOQ: 1 Set -
Stainless Steel Water And Powder Dosing Mixing MachineUS$ 1,000 - 5,000MOQ: 1 Set
-
Hot Sale Stainless Steel Tube Heat ExchangerUS$ 2,000 - 12,000MOQ: 1 Set
-
200 l Steel Drum Type High Effective Batching Barrels With EmulsifierUS$ 1,200 - 6,000MOQ: 1 Set
-
Tube Heat ExchangeUS$ 1,500 - 3,000MOQ: 1 Set
Condition
New
Mixer Type
Agitator
Product Type
Fertilizer
Application
Liquid
Additional Capabilities
Milling
Place of Origin
Zhejiang, China
Brand Name
L&B
Model Number
FCJ series
Max. Loading Capacity
5000L
Voltage
can be design
Power(W)
1.5-4KW
Dimension(L*W*H)
Pending
Certification
ISO, CE
Warranty
1 year
After-sales Service Provided
Overseas third-party support available
Product Description
Working principle:
The magnetic agitating is an application of a magnetic coupling .
Because the repulsion between the different poles of the magnetic material,we drive the magnetic agitator by
continuous changing the polarity of the magnetic base.
The shaft of motor and reducer connect with the inner magneticring ,the agitation shaft connected with the
out magneticring.
The out magnetic ring rotates with the inner magnetic ring ,and make the agitation shaft rotate according.
The inner ring and outer ring are separated by the seal cover.
So it is one of the most reliable No-leak design ,and a necessities for no leak reactors.
| Effective volume | Dimension of tank(D*H) | Total height | Motor power | Blending speed |
| (L) | (mm) | (mm) | (kw) | (r/min) |
| 500 | 840*1000 | 2750 | 0.55 | As customer's requirement |
| 600 | 920*1000 | 2850 | 0.55 | |
| 700 | 990*1000 | 2850 | 0.55 | |
| 800 | 950*1220 | 3000 | 0.55 | |
| 900 | 1010*1220 | 3000 | 0.55 | |
| 1000 | 1060*1220 | 3150 | 0.75 | |
| 1500 | 1160*1500 | 3350 | 0.75 | |
| 2000 | 1340*1500 | 3410 | 1.1 | |
| 3000 | 1410*2000 | 4000 | 1.5 | |
| 4000 | 1620*2000 | 4250 | 1.5 | |
| 5000 | 1810*2000 | 4300 | 2.2 | |
| 6000 | 1980*2000 | 4550 | 2.2 | |
| 7000 | 1930*2440 | 5000 | 2.2 | |
| 8000 | 2060*2440 | 5000 | 3 | |
| 9000 | 2180*2440 | 5050 | 3 | |
| 10000 | 2300*2440 | 5050 | 3 | |
| 12000 | 2270*3000 | 5600 | 4 | |
| 15000 | 2530*3000 | 5700 | 4 | |
| 20000 | 2640*3660 | 6400 | 5.5 |
