500L electric steam heating jacketed kettle vessel
Gas jacket vacuum cooking kettle with pressure
Steam Jacket Cooker
Electric Heating Jacket Cooking Kettle
Gas heating jacket kettle
Name: Stainless steel steam electricjacketed kettle(oil jacketed kettle,jacket kettle with agitator)
Capacity: 50L-1000L with Agitator and jacket
Material: SS304 and SS316 20 years specialized factory
Structure:Double open lid,close head,lifting, pneumatic lift;
1. Stainless steel oil jacketed kettle is composed of kettle, bracket, worm wheel and worm etc.
2. The kettle can revolve with 180°,The equipment is used for open concentration,
mainly for decocting and concentration of liquids in industries of pharmaceutical industry,
food industry, chemical industry and light industry etc.
3. Contact area of the equipment
with materials is made of stainless steel SUS304,which has perfect corrosion—proof performance, and is highly endurable according to GMP requirements.
4. Blender also can be added according customer requirements.
| Model | QJ50 | QJ100 | QJ150 | QJ200 | QJ300 | QJ400 | QJ500 |
| volume | 50 | 100 | 150 | 200 | 300 | 400 | 500 |
| pressure | <0.2 Mpa | ||||||
| evaporating quantity | 30 | 40 | 50 | 65 | 75 | 100 | 150 |
| heating area | 0.4 | 0.45 | 0.76 | 1 | 1.15 | 1.44 | 1.9 |
| energy | 33 | 44 | 55 | 72 | 90 | 110 | 165 |
| weight (kg) | 170 | 190 | 210 | 230 | 320 | 360 | 485 |
| length | 720 | 800 | 1350 | 1400 | 1450 | 1500 | 1600 |
| width | 600 | 650 | 660 | 700 | 800 | 850 | 900 |
| height | 830 | 950 | 1000 | 1100 | 1110 | 1140 | 1150 |
Supply Mixing tank,Reactor tank,fermentation tank,Inline homogenizer,High shear emulsifier mixer,Colloid mill,Jacket cooking kettle,Rotor pump,screw pump,emulsion pump,transfer pump etc.
Wenzhou L&B Fluid Equipment co., Ltd have special technology to design and exploit by CAD software and computer and is a outstanding leader among valve fields. We have advanced CNC lathes imported from Japan. We can manufacture the valves and fitting according to ISO, DIN, IDF, SMS, 3A, while we can produce the products per as the requirement from the clients(non-standard). Our products can get to the international standard and meet the requiement of GMP, so they are widely used in many fields, such as dairy, beer, food, pharmacy, beverage, cosmetic etc.,exported to America, Europe, the Middle East.
