Help CenterProgrammable Networking CANBus Stepper Controller UIM24204
Related Products
-
8 Amps Phase Current Step Controller UIM24208US$ 1 - 200MOQ: 10 Pieces -
Programmable Intelligent Stepper Motor ControllerUS$ 1 - 100MOQ: 1 Piece
-
UIM 241 Stepper Motor Controller Serial Port RS232 InterfaceUS$ 1 - 100MOQ: 1 Piece
-
Networking With CANBus UIM242 Stepper ControllerUS$ 1 - 100MOQ: 1 Piece
-
Step Motor Driver for Hybrid 2 Phase Unipolar Stepping MotorUS$ 10 - 200MOQ: 5 Pieces
Specifications
Nema 17 frame size1.5-4 amps per phase adjustable output current
10-40VDC power supply
CANBus Networking programmable
Nema 17 frame size miniature stepper controller
10-40VDC wide range power supply
1.5-4 amps per phase adjustable output current
Stepper Motor with CANBus 2.0 for Networking controlling of more than 100 stepper motors synchronously or individually
For Integrated Stepper Motor with Motion Controller size Nema 17 and Nema 23
Free software for demostration
With die-cast aluminium Heat Sink for heat radiation
| Driving Mode | Power Supply | Output Current |
| PC Controlled | 10-40V DC | 1.5 to 4 amps |
| PLC | 3 to 8 amps |
Selecting driver mode
FULL-STEP MODE: This is the basic stepper driving mode, it offers the simplest control electronics and it is recommended for high- and mediumfrequency operation. At these frequencies, the inertia of the motor and the load smooth out the torque, resulting in less vibration and noise compared
to low-speed operation.
HALF-STEP MODE: Half stepping with 140% 1-phase-on current gives smoother movement at low step rates compared to full stepping and can be used to lower resonances at low speeds. Half stepping also doubles the system resolution. Observe that for most steppers, the step accuracy specification only is valid for 2-phase-on positions. The accuracy is lower and the stop-position hysteresis is larger for 1-phase-on positions.
MICROSTEPPING: The smoothest movements at low frequencies is achieved with microstepping. Higher resolution is also offered. If resonance-free movement at low step rates is important,
the microstepping driver is the best choice. Microstepping can also be used to increase stop position accuracy beyond the normal motor limits.
