Digital Wall Mount 30ppm Carbon Dioxide CO2 Data Loggers With Dew Point/Wet Bulb Temp TWA / STEL / Lps% / Cfm /P Made in Taiwan

Gain Express Holdings Limited
Digital Wall Mount 30ppm Carbon Dioxide CO2 Data Loggers With Dew Point/Wet Bulb Temp TWA / STEL / Lps% / Cfm /P Made in Taiwan thumbnail-1
Digital Wall Mount 30ppm Carbon Dioxide CO2 Data Loggers With Dew Point/Wet Bulb Temp TWA / STEL / Lps% / Cfm /P Made in Taiwan photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Model Number:
M0198511
Usage:
Household
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Model Number M0198511
Usage Household
Theory Temperature Sensor

Wall mount / Hand held type Carbon Dioxide (CO2)  logger in modern shape with jumbo display  .With Unique six (6) smiley icons which stand for CO2 concentration level.



It complies with all essential health and safety requirements set out in European Directives (CE marking). Plus,all parts are made and manufactured in Taiwan.





Features:

  • Great and fashion shape with NEW DESIGN patent
  • A vented area shape may quick and easy to detect
  • CO2 sensor uses NDIR technology, Automatic baseline calibration function maintains the accuracy
  • Large LCD simultaneously display CO2, Temp, RH
  • Very useful to record CO2 and RH in the mushroom control room for ventilation analysis purposes
  • Hi/Lo alarm threshold is selectable ,easy to reset default setting, audible warning high concentration
  • Recall Max and Min CO2 readings from power on
  • Normally no maintenance is required
  • Using CO2 meter to optimize ventilation and make necessary energy-saving arrangement
  • A higher performance hand held CO2 meter reduce global warming
  • Completely follow the specification of ASHRAE and California IAQ standard.
  • Recording TWA, STEL for safety and lps%, cfm/p for ventilation purposes
  • Environments with ABC on
  • Made in Taiwan



Specifications:

  • LCD display  : 85 x 56mm jumbo size
  • Carbon Dioxide (CO2) measurement
    • Range  : 0~9999ppm
    • Accuracy  : +30ppm +5% of rdg (CO2) 0~5000ppm , others out of scale range
  • LED (Red , Green)
  • Start mode : Schedule , Immediately , Real-time , Button start/stop
  • Stander for desktop
  • Hi / Lo threshold setting with audible alarm
  • Temperature
    • Range :   -40.0~85.0k(-40~185F)
    • Accuracy :   +0.6k(-20~50k),others+1.2k
  • Relative Humidity (RH) %
    • Range :   0.1 % RH ~ 99.9 % RH
    • Accuracy :   +3%RH(at 25k,10~90%RH,others+5%RH)
  • Logger memory capacity :    32000 points
  • Sample interval selection :    0~59 sec. 0~59 min. 0~5 hours
  • Power mode :    LCD model display ON or OFF selectable for saving power
  • Monitor dimension: 109 x 95 x 25mm
  • Power : AC Adaptor (Optional)
  • Operating Temp. RH :   0~50k(32~122F)   , <80%RH
  • Sensor life :  15 years in normal comm.
  • Storage Temp.:   -40~70C(-40~158F)
  • USB, RS485 Interface Optional (Software is optional )



Set includes:
  • 1 x Wall Mount CO2 Logger
  • 1 x Instruction Manual

Optional (not included in set)

Please inform us if you want any of the following optional items to be included in your order

  • RS485 Interface



NOTE:



This product uses NDIR technology for its CO2 sensor. This can only used in non-condensed areas. Not recommened for areas with huge temperature variation (high temp to low temp - cold to warm or to hot place or vice versa).



It is used only at places with constant temperature. Warranty does not cover when it is use in condensed areas.







Smiley icons which stand for CO2 concentration level

Digital Wall mount 30ppm Carbon Dioxide CO2 data loggers with Dew point/Wet Bulb Temp TWA / STEL / lps% / cfm /P Made in Taiwan
