Exhaust Fan for Poultry Farm /ventilation Fan

Qingdao Peng Sheng Electrical Appliance Co., Ltd.
Exhaust Fan for Poultry Farm /ventilation Fan thumbnail-1
Exhaust Fan for Poultry Farm /ventilation Fan thumbnail-2
Exhaust Fan for Poultry Farm /ventilation Fan thumbnail-3
Exhaust Fan for Poultry Farm /ventilation Fan thumbnail-4
Exhaust Fan for Poultry Farm /ventilation Fan photo-1
Exhaust Fan for Poultry Farm /ventilation Fan photo-2
Exhaust Fan for Poultry Farm /ventilation Fan photo-3
Exhaust Fan for Poultry Farm /ventilation Fan photo-4
US$ 20 - 200 MOQ: 1 Piece
Key Specifications
Get Latest Price
Electric Current Type:
AC
Mounting:
Free Standing
Blade Material:
Stainless Steel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type AC
Mounting Free Standing
Blade Material Stainless Steel
Place of Origin Shandong, China
Brand Name PengSheng
Model Number ventilation fan
Voltage 220~450v
Power 550W
Air Volume 12000~46500m3/h
Speed 960-1450r/min
Certification Other, ISO9001
After-sales Service Provided Overseas service center available

Exhaust Fan for poultry farm /ventilation fan



Great all-purpose exhaust fan for agricultural or industrial applications. The molded fiberglass housing of this fan provides for low maintenance, rust free, corrosion free, easy cleaning and high performance.



Corrosion-resistant, reinforced-fiberglass housing with fiberglass mounts and a heavy cast-aluminum blade.





Dimensions


22", ", 26", 36", 42", or 50" available



Standard
Features

  • FAN HOUSING - Molded figerglass; extremely smooth inside for low maintenance, rust free, corrosion free, easy cleaning, and high performance. Lifetime Warranty on all housings and fiberglass mounts.
  • FAN BLADES - Aluminium blades (50" fans), light weight, highly efficient, easy cleaning, balanced for smooth operation and extended life of blade and motor. Fiberglass blades are optional .
  • MOTOR - Tough, energy efficient, totally enclosed, automatic thermal protection, prelubricated ball bearings, dual voltage single/variable speed. 2-Year warranty and 3 phase motors available upon request.
  • SHUTTERS - White, PVC aerodynamically designed for smooth operation and less air drag. Improves fan efficiency. Stainless steel corner clips inside of PVC for strong shutter construction. Nylon pivot on each louver. Aluminum shutters available upon request.
  • FLUSH MOUNT DESIGN - Eliminates any protrusions or obstructions in the barn access area
  • SLANT WALL HOUSING - The perfect design for more efficient air flow



Specifications:



SPECIFICATIONS
ITEM NO.OFS-076SSOFS-085SLOFS-106SLOFS-128SLOFS-146SLOFS-146AT
AIRFLOW14000m3/h19000m3/h25000m3/h36000m3/h45000m3/h48500m3/h
OUTPUT0.39kw0.55kw0.55kw0.75kw0.75kw1.1kw
VOLTAGE/FREQUENCE 380v 50hz380v 50hz380v 50hz380v 50hz380v 50hz380v 50hz
IMPELLER SIZE22"26"36"42"50"50"
IMPELLER MATERIAL Fiberglassfiberglassfiberglassfiberglassfiberglassaluminium
BLADES3  wings6 wings6 wings6 wings6 wings3 blades
ROTATING SPEED960 RPM760 RPM560 RPM560 RPM460 RPM560 RPM
NOISE≥60db≥63db≥65db≥68db≥72db≥75db
WEIGHT30kg36kg42kg48 kg56kg58kg
PRODUCT SIZE76x76x40cm85x85x48cm106x106x55cm128x128x56cm148x148x58cm148x148x58cm
NOTED: THE REQUESTED MOTORS ARE AVAIABLE TO BE ORDERD



Exhaust Fan for poultry farm /ventilation fan

Features:

1.The patented design provides excellent performance without a cone.



2.Thick and corrosion resistance SMC housing with limited lifetime warranty .



3.Rust-free,corrosion-free,smc housing with onterior glossy for high output performance and low maintenance



4.Every feature of cone fan line is designed to maximize performance and durability 6 blanced SMC paddle blades



5.Direct drive fan requiring no belts,no bearings to grease with high efficiency with no drive loss



6.Totally enclosed,maintenance free ,high efficiency direct drive motors



7.Uniques shutter design lower resistance with preventing back drafts



8.Unique motor mount design allows you to quickly and easily remove all interior fan conmponts from inside of the building



9.Self draining ,sloped housing is quick and easy to clean reducing maintenance costs



10.Pvc coated outside guard

Exhaust Fan for poultry farm /ventilation fan



Company introduction



Qingdao Peng Sheng Electrical Appliance Co., Ltd. is a scientific enterprise specializing in the production of air blower, exhaust fan, axial flow fan, centrifugal fan, a negative pressure fan ventilation equipment, company's existingprocessing equipment more than 100 Taiwan (sets), various types of testing equipment more than 20 Taiwan (sets),including the advanced computer control and detection equipment and CNC machining equipment, can satisfy the different customer quality requirements and batch ordering.

Exhaust Fan for poultry farm /ventilation fan

Our Services





1. Official certificate of quality and managemnet.

We approved ISO certificate, whick can be check on official website.



2. After-sale service.

All the model have an ONE YEAR GUARANTEE period, if any part goes wrong, we replace it for free, and we supply parts for maintaining with abusolutely reasonable price.



3. Flexibble payment service.

For good clients we accept Flexible Payments, like T/T, one month L/C, give our clients better purchasing experience and financing.



4. Welcome to visit us!

Visit us and talk to us face to face, inspect our models, when order is placed, we give a good Discount.
 Exhaust Fan for poultry farm /ventilation fan

If you can't find the datas you need, pls send us your performance requirements,

we will provide you customized design service in 8 hours.



sykpe :qdpsdq.dong

moble :+86 13964294505

my name : Zhengdong
