Help CenterGreenhouse Workshop Large Ventilation Exhasut Fan
Related Products
Greenhouse workshop large ventilation exhasut fan
Features:
1.Adopts special shutter pushing device which could open and close shutter automatically.
2.Adopts the punch forming stainless steel blades, no deformation, no breaking, elegant appearance and durability. Calibrated by high-accuracy dynamic balance tester, ensure the stable operation of the fan, reduce noise, and extend service life.
3.Adopts the special recessed transportation handler design, convenient for loading/unloading and transportation, meanwhile, it will not influence the installation and visual appearance of the fan.
4.The V-type belt pulley is cast with high intensity aluminum-magnesium alloy, with light weight and high strength.
5.We could manufacture Type A or Type B belt upon sales situation of dealers, and meet demands of different customers efficiently.
6.Equipped with high efficient and energy-saving electrical motor which had passed the National CCC Certification. Protection grade: IP55; Insulation grade: Grade F.
7.Mechanical centrifugal-type opening facility adopts 100% raw material injection production of strong toughness nylon to achieve high strength and long service life. The steel parts embedded in guide rod are installed on flange, which improves the workability and avoids the telescopic variation of nylon during.
| Model |
Wind leaf size (mm) |
Outer frame dimension (mm) |
Power (kw) |
Air volume (m3/h) |
Total pressure (pa) |
| 95JF-50A | 500 | 620*620*370 | 0.5 | 12900 | 50 |
| 95JF-71A | 710 | 800*800*370 | 0.55 | 17700 | 55 |
| 95JF-90A | 900 | 1000*1000*370 | 0.75 | 20700 | 60 |
| 95JF-100A | 1000 | 1100*1100*370 | 1.1 | 32400 | 62 |
| 95JF-110A | 1100 | 1200*1200*370 | 1.1 | 38400 | 60 |
| 95JF-125A | 1250 | 1380*1380*370 | 1.1 | 40200 | 65 |
| 95JF-140A | 1400 | 1530*1530*370 | 1.5 | 55500 | 60 |
Certification
Our Advantage
1.Small volume, high air volume, high efficiency, low noise, light vibration,easy to installation and so on.
2.Widely applied for the ventilation in dwellings, industrial constructions and labs, in environment with strict limit to noise, or in air conditioning, air purifying and freezing industries etc.
3.The fan adopts mold production through static and dynamic balance adjustment, and its surface adopts high-grade electrostatic spraying treatment.
4.The gas delivered by the series of fan cannot have sticky matters, and is noncorrosive, non-flammable and non-explosive.
FAQ
Why choose Qingdao Peng Sheng Electrical Appliance Co., Ltd.?
1.Good quality, Competitive price, Fast delivery.
2. We have a R&D team who have average 10 years experience in designing and producing fans, we can OEM different kinds of products according to your requirement,
in order to produce the products more suitable to your market !
3. We have a lot of customers from overseas. A lot of our customers has established long term business relationship with us.
4. All the products have 1 year warranty. All products are conducted strict QC and inspection before shipping.
5. If you have any problems or suggestions about our products or service, you can contact me or our sales manager whenever you want. We will give you a satisfying reply.
Contact Way
If you can't find the datas you need, pls send us your performance requirements,
we will provide you customized design service in 8 hours.
