Axial-Flow Fan Stationary Type
Uses and Features
Our factory production of this series fan, with smooth streamlined surfaces, rigid particularly good, the wind impeller member sturdy grille smooth, elegant appearance and tone.
This series of products are widely used in industrial and mining enterprises, civil construction wall exhaust, post air, ventilation pipe. Also used in chemical industry, light industry, medicine, metallurgy, power plants, transportation and warehousing workplace ventilation and air conditioning systems.
DATA:
| Rated speed | 1450r/min |
| Total pressure | 167Pa |
| Static pressure | 80Pa |
| Airflow | 5300m3/h |
| Power | 0.37kw |
| Noise | 72dB(A) |
1. Adopt pressing shell for motor with fine heat dispersing effect.
2. Low noise ball bearing, reset heat protection, long service life motor.
3. Adopt superior light steel sheet pressing structural components with fine rigidity, light weight, good appearance and convenient installation.
4. Adopt CAD optimizing fan blade, large air quantity, low noise and stable operation.
5. Can produce safety guard mesh according to client's demand.
| The main technical parameter | ||||||
| type | machine | retated speed | air volume | total pressure | machine motor | noise |
| NO | r/min | m³/h | pa | KW-P | A | |
| SFG2-2/R | 2800 | 1300 | 140 | 0.12 | 62 | |
| SFG2-4/R | 1450 | 600 | 20 | 0.06 | 57 | |
| SFG2.5-2/R | 2800 | 2100 | 215 | 0.25 | 65 | |
| SFB | SFG2.5-4/R | 1450 | 1000 | 35 | 0.09 | 59 |
| pipeline type | SFG3-2/R | 2800 | 3000 | 230 | 0.37 | 68 |
| SFG3-4/R | 1450 | 2000 | 59 | 0.15 | 61 | |
| SFG | SFG4-2/R | 2800 | 11000 | 320 | 1.5 | 75 |
| fixing type | SFG4-4/R | 1450 | 5300 | 167 | 0.37/0.55 | 72 |
| SFG5-4/R | 1450 | 9300 | 200 | 0.75 | 74 | |
| SFG5-6 | 960 | 7700 | 120 | 0.37 | 66 | |
| SFG6-4 | 1450 | 18700 | 300 | 1.5/2.2 | 80 | |
| SFG6-6 | 960 | 12000 | 180 | 1.1 | 75 | |
| SFG7-4 | 1450 | 24500 | 350 | 3 | 85 | |
| SFG7-6 | 960 | 21500 | 210 | 2.2 | 78 | |
| SFG8-4 | 1450 | 28000 | 380 | 4 | 88 | |
| SFG8-6 | 960 | 25000 | 230 | 2.2 | 82 | |
| SF post type | SFG10-6 | 960 | 50000 | 260 | 4 | 88 |
| SF post type | SF3-4/R | 1450 | 2000 | 59 | 0.12 | 61 |
| SF post type | SF4-4/R | 1450 | 5300 | 167 | 0.37/0.55 | 72 |
| SF post type | SF5-4/R | 1450 | 9300 | 200 | 0.75 | 74 |
| SF post type | SF5-6 | 960 | 7700 | 120 | 0.37 | 66 |
| SF post type | SF6-4 | 1450 | 18700 | 300 | 1.5/2.2 | 80 |
| SF post type | SF6-6 | 960 | 13000 | 180 | 1.1 | 75 |
| SF post type | SF7-4 | 1450 | 24500 | 350 | 3 | 85 |
| SF post type | SF7-6 | 960 | 21500 | 210 | 2.2 | 78 |
Packing &Shipping
Company Profile
Certification
Our Advantage
1.Small volume, high air volume, high efficiency, low noise, light vibration,easy to installation and so on.
2.Widely applied for the ventilation in dwellings, industrial constructions and labs, in environment with strict limit to noise, or in air conditioning, air purifying and freezing industries etc.
3.The fan adopts mold production through static and dynamic balance adjustment, and its surface adopts high-grade electrostatic spraying treatment.
4.The gas delivered by the series of fan cannot have sticky matters, and is noncorrosive, non-flammable and non-explosive.
FAQ
Why choose Qingdao Peng Sheng Electrical Appliance Co., Ltd.?
1.Good quality, Competitive price, Fast delivery.
2. We have a R&D team who have average 10 years experience in designing and producing fans, we can OEM different kinds of products according to your requirement,
in order to produce the products more suitable to your market !
3. We have a lot of customers from overseas. A lot of our customers has established long term business relationship with us.
4. All the products have 1 year warranty. All products are conducted strict QC and inspection before shipping.
5. If you have any problems or suggestions about our products or service, you can contact me or our sales manager whenever you want. We will give you a satisfying reply.
Contact Way
If you can't find the datas you need, pls send us your performance requirements,
we will provide you customized design service in 8 hours.
Skype :qdpsdq.dong
Mobile :+86 13079292921
My name : Zhengdong Lu
