High Pressure Chinese Herb Extractor
Closed tisanes machine volume is big and cooking quickly, it is suitble for big prescription. There are 15L (1.8Kw), 25L(2.2Kw), 40L(3Kw) voulmes, this high pressure closed tisanes machine can be used alone or together with packing machine to improve working efficiency.
1.Total made of 304 stainless steel, 5mm thinkness of the cylinder
2.The solenoid valve is introduced from Korea, steadily control the packing amount
3.Double motor, stable operation
4.Elaborate metal plates
5.Equipped with transformer to stabilize electric current
6.Decocting under high pressure, well closed and retains the original pharmacological action
7.Tasteless, squeezing action
8.Thermal insulating layer attach to the cylinder wall(heat resisting silica
Technical Parameters
Item No. |
YSD-G25 |
YSD-G40
|
BAB-2-G15
|
Packing capacity(bags/min) |
none |
none |
7 |
Packing capacity(ml) |
none |
none | 50-290 |
Voltage(v) |
220 |
220 |
220 |
Power(kw) |
2.2 |
4.2 |
4.5 |
Cylinder volume(L) |
25 |
40 |
15*2 |
Weight(kg) |
56 |
70 |
150 |
Overrall size(mm) |
495*480*1150 |
600*580*1260 |
1350*630*1400 |
Machine operation
Ready work: packed the herb by specical non-woven fabrics pocket, tie the pocket month, put into tank and soak into water about 30min;
Clean herb tisanes machine, open the waste liquid valve and inject clean water, close waste liquid valve and liquid outlet valve, put soaked non-woven fabrics pocket into herb tisanes machine cylinder, then add soaked liquid and water.
Water rate (for reference): water yield=need herb liquid+20%=(package volume*daily times*herb package)*1.2.
Operation step: put herb and water into herb tisanes machine, close the cover, revolve hand shank tightly, close air outlet safety valve. Then set extracting time,extracting temperature, press down heating button, machine will heat aoutomatically. It will change into slow fire until reach setting temperature and stop heating until reach extracting time.
After finished, open air outlet valve to reduce the pressure (make the pressure about 1Kg), then open liquid outlet valve to send herb iquid to package machine. Please operate compact dreg pillar to make herb liquid come out more. After pour out all the herb liquid, open the air outlet valve full to reduce pressure as the same as outside, and then open the hand shank to take out the herb pocket, shup down power supply and clean the machine again.
Attention
- Ground connect to keep safe;
- The electric part can’t be water by water;
- Must open the air outlet valve to reduce cylinder inside pressure before openning the cover;
- Do not pen waste liquid outlet valve during heating, or it is not safe;
- Must clean the cover and sealed contact face, anti residue liquid adhere the sealing;
- Please inspect the sealing ring and ensure the seal is good before start heating;
- If the non-woven fabrics pocket is broken during extracting, please clean the dregs, or it will cause jam when packing.;
- Do not heat if there is no water inside;
- When lock the cover, please lock evenly one by one, or the cylinder will be destroyed;
-
If the actual heating time is not finished under setting in last time, please shut down the powder supply to make the counter zero setting before heating, or the heating time is the original one, it will stop heating after reach the setting time
Our other machines
standard exporting plywood case packing
inner package: stretch film
Guangzhou Laymax Machinery is a professional manufacturer of food processing machine and pharmyceutical Equipments.
Our main pharmyceutical equipments are: single punch tablet press machine, rotary tablet press, granulator, pill making machine, powder mixer, blister packing machine, capsule filling machine, granule packing machine, tisanes packaging machine, tablet/capsule counter, Chinese medicine slicer, sugar/film coating machine and so on.
Main food equipments are: fineness powder grinder, Chinese medicine grinder, grains mill, sesame mill, coffee grinder, flour mill, pepper grinder, water cooling universal grinder, corn crusher, maize milling machine, cereal mill, cassava grinder, rice milling machine, spice grinder etc.
We also have meat process machine, like meat grinder, meat bone cutter, meatball making machine, stuffed meatball machine, meat slicer, sausage stuffing machine, mince meat machine and some other machhine as peanut oil extractor, drying oven, vacuum oven, nuts roaster.
On the basis of advanced equipment and workmanship, we have excellent production technicians and an efficient distribution team, as well as good service staff members, so that we can undertake your orders very efficiently. When we have the confidence on the high quality of our products, we offer very competitive prices at the same time.
1. Professional engineer to service;
2. Factory good price;
3. Once any after service happen, response in 24hours;
4. Supply machine working DV if neccessary
Pls contact with us if any questions about our machines
