price for tablet press machine/mini press tablet machine
There is only one punching die on this machine, both material filling depth and tablet thickness are adjustable. It suits different kinds of abroad medicine, Chinese medicine area and also other referring area, it is deep welcome in the market.
Single Punch Tablet Presses Application range
It is suitable for medicine factory, chemical factory, hospital, researching company and laboratory.
Punch Dies
6mm, 8mm, 10mm, 12mm round punching die we can offer anytime
Other irregular shape tablets ,please contact us for more information
Technical parameter for single punch tablet press machine:
Type |
DYP-1.5T |
DYP-1.5L |
DYP-1.5W |
DYP-5T |
DYP-6T |
Dies |
1 set |
1 set |
1 set |
1 set |
1 set |
Max.Pressure(KN) |
15 |
15 |
15 |
50 |
60 |
Max.dia.of table(mm) |
12 |
12 |
12 |
18 |
25 |
Max.Depth of fill(mm) |
12 |
12 |
12 |
16 |
16 |
Thickness of largest table(mm) |
6 |
6 |
6 |
9 |
9 |
Production capacity(pcs/h) |
6000 |
6000 |
6000 |
6000 |
5000 |
Motor(KW) |
0.55 |
0.37 |
0.37 |
0.75 |
1.5 |
Operating method |
Driven Motor/Man power |
Driven Motor/Man power |
Driven Motor/Man power |
Driven Motor/Man power |
Driven Motor/Man power |
Overall size(mm) |
570×380×630 |
530×360×590 |
550×470×550 |
650×440×650 |
750×380×700 |
Material of machine |
Iron |
Aluminum alloy |
Al. Whirling type |
Iron |
Iron |
Net weight(kg) |
95 |
45 |
40 |
128 |
165 |
Differences among DYP-1.5W,DYP-1.5L,DYP-1.5T
The contact parts of powder/particles are 304SUS
Iron press(DYP-1.5T) can produce tablet more compact by heavy weight.
Aluminum press(DYP-1.5L),Anti rusty,easy to move,popular with lab or school teaching
DYP-1.5W,,worm gear driven the pressure instead of flywheel,low noise(it won't trouble people next the door)
Tablets
Original herb medicine to capsule process,click the picture,you will know more details
2nd,dry medicine grinded into 100mesh or more fine powders
3rd,Mixing various medicine powders
4th,Granulating powders into particles,granular has stronger fluxility
5th,Particles would be pressed into tablet/pills
Or powders produce into pills directly.
6th,we will polish and coating film on tablet/pill by film coating machine
7th,Blister packer for tablet/pill/capsule packaging for sale
8th capsule counter&filler
or Herb powders for filling capsule
We also have supporting equipments,click the item ,you will know more
260 degree Drying carbinet/Air convection
Laymax Manufactured Degassing Chamber Vacuum Drying Oven Stainless Steel
150-400mesh powder grinding machine FS30C
Luxury Quantitive Auger Feeding Grinding machine/Mill for sale
FS230 Hammer Iron Grinder Machine
Quality Spices&Herbs Grinder in Laymax
3D Mixer Dry Powder Mixer
Pharmaceutical Granulator YK-60
Manual Tablet compression machinery DYP-0
DYP-1.5L Desktop Tablet Press
Aspirin Tablet Press DYP-6T
Tablet Machine XYP-9B
Inquiry now!
Package way: Wooden case or carton
Established in the year of 2011, Our factory is a professional in exporting the following machines:
1, Drying equipment
2, Grinding machinery
3, Pharmaceutical & Chemistry machinery
4, Food machinery
5, Agricultural machinery
Credits and Certificates:
1. Q: How long is your guarantee?
A: One full year warranty from us starting from the day you got our goods.In most cases when item got problems we shall send you necessary parts for your own replacement so you needn't return the machine to us for repairing. And we shall provide online technical guide for you to replace the parts.
