200kva Volvo Diesel Generator

Specifications

200kva Volvo Diesel Generator
1)Volvo Industrial Engine
2)Stamford Alternator
3)Globally Servic
4)ISO9001:2008 & CE

   200kva Volvo Diesel Generator

Volvo have been widely used in large and small automobiles, heavy-duty trucks, engineering machineries and ships. Moreover, they are the ideal drive force of power generation sets. Volvo engines have high load capability as well as fast and reliable cold start performance.



Genset Model	Prime Power		Standby Power		Engine	Fuel Consumption	Cylinder No.	Displacement	Bore X Stroke
	KW	KVA	KW	KVA		(g/kwh)		(L )	(mm)
GNRV95	68	85	76	95	TD520GE	≤213	4	4.67	108*130
GNRV110	80	100	88	110	TAD531GE	≤211	4	4.67	108*130
GNRV137	100	125	110	137	TAD532GE	≤204	4	4.67	108*130
GNRV165	120	150	132	165	TAD731GE	≤204	6	6.51	108*130
GNRV200	144	180	160	200	TAD732GE	≤204	6	6.73	108*130
GNRV225	160	200	180	225	TAD733GE	≤204	6	7.28	108*130
GNRV275	200	250	220	275	TAD734GE	≤200	6	7.28	108*135
GNRV350	250	312	280	350	TAD941GE	≤198	6	9.36	131*150
GNRV413	300	375	330	413	TAD1241GE	≤198	6	12.3	131*150
GNRV450	320	400	360	450	TAD1242GE	≤198	6	12.3	131*150
GNRV500	360	450	400	500	TAD1640GE	≤198	6	16.12	144*165
GNRV560	400	500	450	560	TAD1641GE	≤198	6	16.12	144*165
GNRV625	450	563	500	625	TAD1642GE	≤198	6	16.12	144*165
GNRV688	500	625	550	688	TAD1643GE	≤198	6	16.12	144*165





Alternator

1. alternator brand: Stamford,LeroySomer, Marathon,Engga
2. Excitation: harmonic excitation or phase compound or brushless self excited
3. Phase:3 phase or single phase
4. Connection: Y connection or other type
5. Rated speed:1500/1800RPM, IP21-23
6. Regular: Automatic, deviation rate:+-5%
7. Power factor:0.8



Control Panel

1. control panel: Smartgen, Deepsea,ComAp
2. Automatic alarm system
3. Temperature meter, fuel meter, overload meter, over speed meter, over current meter
4. Emergency stop button
5. Option: AMF and ATS function



Accessories:

1. Standard accessories: standard 40 radiator mounted on skid, common steel frame, circuit breaker damper, exhaust silencer, flexible pipe, standard tool skit, optional manual and documents

2. Optional accessories: oil heater, alternator space heater, communication interface, battery charger, daily fuel tank, ATS and paralleling system, etc



Warranty policy:

Guarantee for one year or 1000 hours of the total running time. During the guarantee period, we will supply freely the easy damaged parts for the possible problems except for the incorrect operation. After expiration, we supply cost spare parts for gen set maintenance
