450kw Soundprood Engine TAD1642GE Volvo Generator

450kw Soundprood Engine TAD1642GE Volvo Generator thumbnail-1
450kw Soundprood Engine TAD1642GE Volvo Generator photo-1
US$ 48,595 - 55,695 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Volvo
Model Number:
GNRV
Contact Supplier Request Quote Chat Now
Shenzhen Genor Power Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Volvo
Model Number GNRV
Output Type AC Three Phase
Speed 1500rpm or 1800rpm
Frequency 50Hz or 60Hz
Rated Power 85kva to 625kva
Rated Voltage 220V/380V, 230V/400V, 240V/415V
Rated Current 122A to 900A

Specifications

TAD1642GE Volvo Generator
-Volvo Diesel Engine
-Stamford alternator
-Deepsea controller
-Noise Level:70dBA at 7m away

      450kw Soundprood Engine TAD1642GE Volvo Generator



volvo have been widely used in large and small automobiles, heavy-duty trucks, engineering machineries and ships. Moreover, they are the ideal drive force of power generation sets. Volvo engines have high load capability as well as fast and reliable cold start performance

450kw Soundprood Engine TAD1642GE Volvo Generator



Genset ModelPrime PowerStandby PowerEngineFuel ConsumptionCylinder No.DisplacementBore X Stroke
KWKVAKWKVA(g/kwh) (L )(mm)
GNRV9568857695TD520GE≤21344.67108*130
GNRV1108010088110TAD531GE≤21144.67108*130
GNRV137100125110137TAD532GE≤20444.67108*130
GNRV165120150132165TAD731GE≤20466.51108*130
GNRV200144180160200TAD732GE≤20466.73108*130
GNRV225160200180225TAD733GE≤20467.28108*130
GNRV275200250220275TAD734GE≤20067.28108*135
GNRV350250312280350TAD941GE≤19869.36131*150
GNRV413300375330413TAD1241GE≤198612.3131*150
GNRV450320400360450TAD1242GE≤198612.3131*150
GNRV500360450400500TAD1640GE≤198616.12144*165
GNRV560400500450560TAD1641GE≤198616.12144*165
GNRV625450563500625TAD1642GE≤198616.12144*165
GNRV688500625550688TAD1643GE≤198616.12144*165



The specification of engine:

1) engine model:  Volvo

2) engine part :water tower,fan,fuel tank

3) governor system:electrical or mechanical governor

4) aspiration mode:natural, turbocharged

5) start method: 12V/24V DC electric starting

6) low fuel cnsumption,low noise,small volume,light weight

7)3 filter( air cleaner,fuel cleaner,oil cleaner),quality certification, Garantiekarte, using instructions





The specification of alternator:

1)alternator model: stamford, Leroy, Marathon.Engga

2)regulator: AVR automatic voltage regulating

3)insulation degree: H degree

4)power factor:3 phase 4 wire

5)Motor: bronze brushless

6) IP21-23 enclosure





 Control system:
1) Automatic alarm system: the unit hasunit has the acousto-optics alarm system and arreand arrestor for anr for any situation as the start defeat, the water is over tempeer temperature, the oil pulls down, over speed, over load and over current
2) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible Audible and visual alarm lamps and buzzers



 optional:



1)Auto-remove Monitor Panel

2)Auto Transfer System(ATS)

3)Auto-combine Cabinet

4)Sound proof canopy

5)Intelligent controlling system





 450kw Soundprood Engine TAD1642GE Volvo Generator450kw Soundprood Engine TAD1642GE Volvo Generator450kw Soundprood Engine TAD1642GE Volvo Generator
