Specifications
Towable Diesel Engine Trailer Mounted Light Towers 6kw1.World Brand Diesel Generator
2.9m Mast with 4 Light Tower
3.CE
Towable Diesel Engine Trailer Mounted Light Towers 6kw
Parameters:
MODEL |
GNR-4000M |
Mast |
|
Maximum extention of mast |
9m |
Elevation |
Mechanical |
Rasing / Lowing mast |
Winch(Mechanical) |
Stages |
3 |
Turning angle |
360 degree non-continuous |
Lamp | |
Total power of lamps |
4*1000W |
Type of lamp |
Metal halide lamp |
Light capacity |
4*110,000 lumen |
Frequency |
50Hz / 60Hz |
Lifetime of lamp |
2000 hours |
Working temperature |
<85°C |
Connection protection index |
IP54 |
Light Coverage |
5 to 7 acres |
Characterisitics of the generator | |
Model |
GNRK6 |
Rated power |
50Hz 5.6 kW |
Standby power |
50Hz 6.2 kW |
Voltage |
110,120,220,230,240 |
Engine model |
Kubota D905 Diesel |
Engine type |
3 Cylinder, in line, water-cooled |
Engine speed |
50Hz 1500 rpm 60Hz 1800 rpm |
Starting systerm |
12VDC |
Alternator |
Brushless,self-excitation with AVR |
Prime fuel consumption at 100% load |
2.0L/h |
Fule tank capacity |
100L |
Emission level |
EU Stage IIIA |
|
|
Trailer | |
Tow hitch |
Ring or ball hitch |
Stabilier Support |
5 × manual |
Tire Size |
185/60R14 |
Anti-wind capacity |
≤10 |
Brakes |
Manual |
|
|
Dimension & Weight |
|
Retracted Dimension |
4300 × 1120 × 1730 L×W×H mm |
Container load (20FT / 40FT) |
6 / 12 units |
Net weight |
790 Kgs |
Engine Features:
1. World most famous brand diesel engine: Kubota/Yanmar/Perkins/Cummins
2. Mufti-cylinder in-line or veer engine, 4-stroke, direct injection
3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
4. Machinery or electronic governing
5. Fuel injection pump
6. Electric motor starting system
7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
8. Low discharge, and low fuel consumption
9. Installed conveniently and maintain easily
Alternator Features:
1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon, ENGGA
2. Brushless, 4 poles, rotation magnet
3. IP21-23(NEMA1) enclose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: ≤±1%
Soundproof/Slient Box:
1. Excellent ventilation
2. Oil tank mounted on base frame for 12 Hours working
3. Highly Corrosion Resistant construction
4. Excellent Access for Maintenance
5. Security and safety
6. 1m<80dB/7m<70dB
Control Panel:
1. Automatic control panel(AMF), LCD display
2. Four protection systems
3. Emergency stop
Optional:
1. Trailer type
2. Soundproof/water proof
3. ATS(automatic transfer switch)
4. Parallel system
5. Remote system
