Mitsubishi Diesel Engine Generator Set

Specifications

                   Mitsubishi Diesel Engine Generator Set

Our company  install Original Mitsubishi diesel engine from Japan with Stamford or Marathon alternator and Auto-start controller.

 The feature of Mitsubishi series diesel generating sets

Steady $ credible running, high shock resistance, strong load resistance, sufficient output power.

Low oil consumption, low emission;

Easy and cheap maintenance;

Small and light figure

 Electric capability of  diesel generator sets.

Be up to the GB2820.3&ISO8525 G3 class standard, and meet the requirement of YD/T502

Technical requirement of special diesel generating set for telecom.

Voltage Regulation(%):Steady state≤±1 Transient state -15~+20

Frequency Regulation(%):Steady state≤±1 Transient state -7~+10

Voltage Fluctuation ratio(%):≤0.5

Frequency Fluctuation ratio(%):≤0.5

Voltage stabilization time(When the load changes suddenly): ≤1S

Frequency stabilization time(When the load changes suddenly): ≤3S

Waveform Distortion(%):≤5

Radio interference suppression: Be accordant with the standard of VDE0875-N Class&GB2820

To meet the customer need, we can also provide 60HZ generator set which is accordant with the international regulation.

 Diesel Engine

Stroke: 6-16

Combustion system: Direct spray or Electronic spray

Start: DC start

Cooling: Coolant radiator with fan

AC Generator

Structure Characteristics: Single bearing, automatic voltage regulation (AVR)

Excitation: Brushless & self-excited

Insulation: H grade

Level of protection: IP21 or IP23

control Box

Manual/Automatic start & stop controller

Various Monitor Meter and Optional Switch

Remote control interface and Remote monitor/Remote Sense/Remote Meter (Optional)

MCCB for Short circuit & Overload (optional)

High water temperature alarm, Low oil pressure alarm, over speed alarm and other kind of alarm

Standard scope of supply

 Diesel generating set include:

Diesel engine (with all standard accessories, filters and electric system)

Radiator (with water tank and fan)

Alternator

Control panel

Steel base frame

All above parts are assembled into a whole
