600kw to 1200kw Diesel Engine Open Type Mitsubishi Generator Set

Specifications

Open Type Mitsubishi Generator Set
1.Mitsubishi diesel engine
2.brushless ac alternator
3.low fuel consumption
4 CE

600kw to 1200kw Diesel Engine Open Type Mitsubishi Generator Set



Genset Features:
1. World-class quality
2. Economical cost, high reliability and durability
3. Small in size and light weight
4. Low noise and stable performance
5. Profesional configuration and premium quality
6. Worldwide reputation and global renown.

Engine Features:
1. Highly volumetric efficiency and combustion efficiency, take use of mobile combustion and fuel injection etc., the combustion chamber is filled up with air evenly which can be burned fully!
2. Advanced electronic fuel injection system to ensure the low fuel consumption, low vibration and noise, high durability of belt.
3. Excellent emission performance, use hot-wire oxygen sensor, exhaust recirculation system, fuel and vapor recycling system, crankcase forced ventilation devices, unique test of air flow etc related technologies.

Alternator features:
(Optional: Stamford, Leroy-somer, Engga, Marathon )
1. Brush-less, 4 poles, rotation magnet
2. IP21-23 (NEMA1) enclosure is standard for all industrial alternators
3. The insulation system is class H
4. Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts
5. Wide range of flange adaptors and single bearing disc coupling
6. Standard 2/3 pitch windings avoid excessive neutral currents

Control System
Manual/Automatic start & stop controller
Various Monitor Meter and Optional Switch
Remote control interface and Remote monitor/Remote Sense/Remote Meter (Optional)
MCCB for Short circuit & Overload (optional)
High water temperature alarm, Low oil pressure alarm, over speed alarm and other kind of alarm

Warranty:
1. Since gen-set reached the agreed destination, its main parts will be guaranteed within 12 months or 1000 hours. (Subject to the earlier mature term).
2. We take charge of all troubles caused by gen-set's fault and repair according to the regulation stipulated by original plants.
3. Factors not accordance with the regulation of original plants such as fragile parts, daily consumed components, wrong operating, lack of maintenance are not include in the quality guarantee.









Genset Model	Prime Power		Standby Power		Engine	Fuel Consumption	Cylinder No.	Displacement	Bore X Stroke
	KW	KVA	KW	KVA		(g/kwh)		(L )	(mm)
GNRM413	300	375	330	413	S6B3-PTA	≤211	6	14.6	135*170
GNRM500	360	450	400	500	S6A3-PTA	≤213	6	18.6	150*175
GNRM550	400	500	440	550	S6A3-PTAA	≤213	6	18.6	150*175
GNRM650	480	600	520	650	S6R-PTA	≤206	6	24.5	170*180
GNRM750	520	650	600	750	S6R2-PTA	≤205	6	30	170*220
GNRM825	600	750	660	825	S6R2-PTAA	≤211	6	30	170*220
GNRM908	660	825	726	908	S12A2-PTA	≤214	12	33.9	150*160
GNRM1125	800	1000	900	1125	S12H-PTA	≤206	12	37.1	150*175
GNRM1375	1000	1125	1100	1375	S12R-PTA	≤205	12	49	170*180
GNRM1500	1100	1375	1200	1500	S12R-PTA2	≤205	12	49	170*180
GNRM1650	1200	1500	1320	1650	S12R-PTAA2	≤205	12	49	170*180
GNRM1650	1200	1500	1320	1650	S16R-PTA	≤207	16	65.4	170*180
GNRM1875	1300	1625	1500	1875	S16-PTA	≤207	16	65.4	170*180
GNRM2100	1500	1875	1680	2100	S16-PTA2	≤207	16	65.4	170*180
GNRM2250	1600	2000	1800	2250	S16-PTAA2	≤207	16	65.4	170*180
