Home > Products > Kubota generator set > Kubota silent diesel generator 10kw 3 phase ats
Kubota silent diesel generator 10kw 3 phase ats
- 200 Set / Sets per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Kubota | |
| Model Number | GNR | Output Type | AC Three Phase | |
| Speed | 1500rpm or 1800rpm | Frequency | 50Hz or 60Hz | |
| Rated Power | 10kw | Rated Voltage | 127V/220V, 220V/380V, 230V/400V, 240V/415V | |
| Rated Current | 18A |
Product Description
Kubota silent diesel generator 10kw 3 phase ats
Kubota generator widely used in the area of industry, railway and construction. The engine is imported from Japan. The global service net of Superwatt and Kubota can provide our customers with reliable and guaranteed service.
| Genset Model | GNRK10 |
| Prime Power | 10/ 12.5(KW / KVA) |
| Standby Power | 11 / 14(KW / KVA) |
| Frequency (HZ) | 50 |
| Voltage (V) | 127v/220v, 220v/380v,230v/400v, etc. |
| Power Factor | 0.8 |
| Phase | 3 |
Kubota Engine
| Engine Model | V1505-E2BG |
| Number of Cylinders | 4 |
| Cylinder arrangement | Vertical in line |
| Cycle | 4 Stroke |
| Aspiration | Naturally Aspiration |
| Bore x Stroke | 78 X 78.4 (mm x mm) |
| Displacement (L) | 1.498 |
| Compression ratio | 22 : 1 |
| Prime Power/Speed | 13.7 / 1500(KW / rpm) |
| Standby Power/Speed | 15.4/ 1500(KW / rpm) |
| Speed Governor | Electrical |
| Cooling System | Water-cooled, 40°C Radiator |
| lubrication capacity | 22(L) |
| Coolant capacity | 6.0(L) |
Original Stamford Alternator:
| Alternator Brand | Original Stamford |
| Alternator Model | PI044F |
| Prime Power | 10KW / 12.5KVA |
| Rated Current (A) | 32.8,19.0,18.0,etc. |
| Rated Voltage | 127V/220V,220V/380V, 230V/400V,etc |
| Frequency | 50HZ 1500rpm |
| Power Factor(COS) | 0.8 |
| Phase / Connection | 3-phase 4-wire , Y type connection |
| Excitation | Brushless, Self-excited |
Insulation Class: H . Protection Grade : IP23. | |
| Voltage Regulation | AVR |
options: Leroy Somer, Marathon, Engga
Soundproof/Silent Box:
1 Cold steel materials of the canopy. & Best powder paint.
2 Stainless steel locks and hinges.
3 Fireproof, waterproof and dustproof.
4 Good ventilation system and anti-heat radiation struction.
5 Effective anti-vibration devices to ensure the generator set run steadily.
6 High quality soundproof materials could efficiently reduce noise.
(lower than 68 dB at 7 meters away)
7 Emergency stop button mounted outside.
8 Side lockable door easy for maintenance and installation.
9 Lube oil and cooling water drains piped to exterior of the canopy.
10 Access to all weather conditions.
Control Plane
1. Solve your technical problems in 24 hours and provide international warranty service for engines
2. Design the appearance form according to customers’ request
3. Polyester varnish for appearance protecting for shining and raining
4. Four hours testing before out factory
5. ISO9001 and CE certification
