Specifications
japanese kubota home generator1) Kubota Generator 10kva to 35kva
2) DeepSea control system.
3) 1year warranty
japanese kubota home generator
Kubota generator widely used in the area of industry, railway and construction. The engine is imported from Japan. The global service net of Superwatt and Kubota can provide our customers with reliable and guaranteed service.
| Genset Model | Prime Power (kva) | Engine Model | Cynlinder No. | Bore x Stroke | Displace -ment | Compression Ratio | Packing (mm) (L x W x H) |
| GNR-K10 | 10 | V1505-E2BG-CHN-1 | 4 | 78 x 78.4 | 1.498 | 24:1 | 2000 x 960 x 1100 |
| GNR-K13 | 12.5 | D1703-E2BG-CHN-1 | 3 | 87 x 92.4 | 1.647 | 23:1 | 2000 x 960 x 1100 |
| GNR-K18 | 17.5 | V2203-E2BG-CHN-1 | 4 | 87 x 92.4 | 2.197 | 23:1 | 2000 x 960 x 1100 |
| GNR-K20 | 20 | V2003-T-E2BG-CHN-1 | 4 | 83 x 92.4 | 1.999 | 23:1 | 2000 x 960 x 1100 |
| GNR-K28 | 27.5 | V3300-E2BG2-CHN-1 | 4 | 98 x 110 | 3.318 | 22.6:1 | 2300 x 1100 x1300 |
| GNR-K35 | 35 | V3300-T-E2BG2-CHN-1 | 4 | 98 x 110 | 3.318 | 21.8:1 | 2300 x 1100 x1300 |
• Features:
Rated output: 10kva to 35kva
Rated voltage: 127V/220V, 220V/380V, 230V/400V, 240V/415V
Rated frequency: 50/ 60Hz
Power factor: 0.8
• Engine: kubota
Cooling method: closed water cooling and air force cooled
Starting method: electric start
Rated speed: 1, 500/ 1, 800rpm
Noise level: 75dB to 80dB 7 meter away
• Alternator:
Rated output: 10kva to 35kva
Rated voltage: 127V/220V, 220V/380V, 230V/400V, 240V/415V
Rated Frequency: 50/ 60Hz
Power factor: 0.8
Phase: 3-phase, 4-wire
Connection: Y or other type connection
Rated speed: 1, 500rpm/ 1, 800rpm
Excitation: harmonic excitation or phase compound or brushless
Voltage regulation: automatic
1.0% voltage regulation ( max.) in static conditions
Protection class: IP 21-23
• Control panel:
The generator control panel have three style for diffrent markets required
Mcb of suitable rating with overload and short circuit protection
With AMF control panel or with ATS ( automatic transfer syste)
