Diesel Generaot Fuel Consumption-Yanmar engine
-1000 hours warranty
-low fuel consuption
-24 hours servic
Diesel Generaot Fuel Consumption
Prime diesel generator:Yanmar engine(3TNV88)+Marathon(GM-6.6-4)/Stamford(PI0444D)+Auto-start controller:
Be up to the GB2820.3 & ISO8525 G3 class standard, YD/T502- Technical Requirement.
Voltage Regulation(%): Steady state≤±1 Transient state-15~ +20
Frequency Regulation(%):Steady state≤±1 Transient state-7~ +10
Voltage Fluctuation ratio(%): ≤0.5
Frequency Fluctuation ratio(%): ≤0.5
Voltage stabilization time (When the load changes suddenly): ≤1S
Frequency stabilization time (When the load changes suddenly): ≤3S
Waveform Distortion(%): ≤5
Radio interference Suppression: Be accordant with the standard of VDE0875-N Class & GB2820
To meet the customer need, we can also provide 50Hz generator set which is accordant with the International regulation.
Diesel Engine:
Stroke: 3;
Combustion system: Direct spray or Electronic spray;
Start: DC start;
Cooling: Coolant radiator with fan.
AC Generator:
Structure Characteristics: Single bearing, automatic voltage regulation(AVR);
Excitation: Brushless & self-excited;
Insulation: H grade;
Level of protection: IP 21 or IP 23.
Control Box:
Manual/Automatic start & stop controller;
Various Monitor Meter and Optional Switch;
Remote control interface and Remote monitor/Remote Sense/Remote Meter (Optional);
MCCB for Short circuit & Overload (optional);
High water temperature alarm, Low oil pressure alarm, Over speed alarm and other kind of alarm.
Standard scope of supply:
Diesel engine(with all standard accessories, filters and electric system);
Radiator (with water tank and fan);
Alternator;
Control panel;
Steel base frame;
All above parts are assembled into a whole.
Other standard parts:
Effective muffle;
Exhaust elbow;
Belows;
Storage battery and connection wires;
Shock absorber;
Technical documents.
Optional equipments:
Auxiliary device for starting at low temperature;
ATS (Automatic transfer switch);
Genset combined Device;
Water forewarmer;
Moisture eliminator of alternator;
Various kind of monitoring system;
Remote monitoring system;
Fuel tank for daily use or base frame fuel tank.
Other kinds of special equipment:
Soundproof canopy;
Mobile Diesel Generating set;
Container Generating set;
Power Station for refrigerated container Generator set;
Gantry Diesel Generator set.
Note:
1. The above data is only for the customers reference.
2. Those above data are for 60Hz, 1800 rpm, 440V/254V, 3 phases 4 wires. Please contact with us if you need 50Hz specification Or else.
3. We reserve the rights to amend the technical specification here without prior notice
