With Perkins Diesel Engine 130kw Commercial generator sets
UK imported Engine generator have earned a reputation for ease of service along with low costs of maintenance and repair and all Pekins Power part products carry an unequivocal 12-months warranty from date of purchase.
Genset Features:
1. Genuine UK imported Engine industrial diesel engine
2. Radiator 40°C max, fans are driven by belt, with safety guard
3. Genuine stamford. Leroy somer, marathonm, engga alternator
4. Choice of manual/auto and AMF control panels and protection systems
5. Digital auto-start panel
6. Anti Vibration Suspension Absorber
7. Dry type air filter, fuel filter, oil filter
8. 10-hour operation base tank
9.Mould case circuit breaker
10. 24V DC start motor and storage battery
11. 24V charge alternator
12. 24V batteries, rack and cable
13. Rippl;e flex echaust pipe, exhaust siphon, flange, and muffler
14. Comply with ISO and CE standards
15. All generator sets are gone through rigorous testing before beging released to the market place, including 50% load, 75% load, 100% load and all protection function(over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)
| GENERATOR SET MODEL | GNRP120 | |
| Voltage | 400V/230V | |
| Frequency | 50Hz | |
| Power factor | 0.8 | |
| Phase | 3Ph 4Wr | |
| Prime Output (kW/kVA) | 96/120 | |
| Standby Output(kW/kVA) | 106/132 | |
| TECHNICAL DATA | ||
| DIESEL ENGINE MODEL | 1006TAG | |
| Engine Characters | water-cooled,inline,4 strokes,direct injection, | |
| Constant Output (kW/kVA) | 121/151.3 | |
| Standby Output (kW/kVA) | 133/166.4 | |
| Aspiration | Turbocharged | |
| Bore(mm) X Stroke(mm) | 100x127 | |
| Piston Speed (m/s) | 7.62 | |
| Compression Ratio | 17:1 | |
| Exhaust Temperature | 550 | |
| Lube Capacity | 8.1L | |
| No.of Cylinder | 6.L | |
| Displacement | 6.23L | |
| Rating Fuel Consumption (L/h) | 27.1 | |
| ALTERNATOR | ||
| Brand | STAMFORD | |
| Model | UC1274D | |
| Continuous Output(kW/kVA) | 96/120 | |
| Power Efficiency | 90.80% | |
| Excitation Type | Brushless | |
| Insulation Class | H | |
| DIMENSIONS AND WEIGHTS | ||
| Dimension(mm) | 2545*850*1650 | |
| Gross Weight | 1370kg | |
Soundproof/Silent Box:
1. Excellent ventilation
2. Oil tank mounted on base frame for 12 Hours working
3. Highly Corrosion Resistant construction
4. Excellent Access for Maintenance
5. Security and Safety
6. 1m<80DBA / 7m<70DBA
Control Panel:
1. Automatic control panel (AMF), LCD display
2. Four protection systems
3. Emergency stop
Optional:
1. Trailer type
2. Soundproof / water proof
3. ATS (automatic transfer switch)
4. Parallel system
5. Remote system
PMC System:
1. Standard 23 pitch windings avoid excessive neutral current
2. Permanent magnet generator system provides constant excitation under all condition
3. Optional accessories available for easy paralleling with mains or other generators
4. AVR auto voltage regulation, auto exciter, auto adjustment
