75kva-165kva Low Rpm Generator

75kva-165kva Low Rpm Generator thumbnail-1
75kva-165kva Low Rpm Generator photo-1
US$ 3,589 - 12,595 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UK
Model Number:
GNRP
Contact Supplier Request Quote Chat Now
Shenzhen Genor Power Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name UK
Model Number GNRP
Output Type AC Three Phase
Speed 1500rpm or 1800rpm
Frequency 50Hz or 60Hz
Rated Power 20KVA To 1250KVA
Rated Voltage 220V/380V, 230V/400V, 240V/415V
Rated Current 29A To 1800A

Specifications

Low Rpm Generator
1.Famous brand :perkins engine
2.Stamford alternator
3.Reliable quality
4.low rpm

  Low rpm Generator



Diesel  power generator  have earned a reputation for ease of service along with low costs of maintenance and repair and all Power part products carry an unequivocal 12-months warranty from date of purchase.



75kva-165kva Low rpm generator





Genset Model Prime Power Standby Power Engine Fuel Consumption Cylinder No. Displacement Bore X Stroke
KW KVA KW KVA (g/kwh)  (L ) (mm)
GNRP10 7 9 8 10 403D-11 ≤252 3 1.131 77*81
GNRP15 10 13 12 15 403D-15 ≤264 3 1.496 84*94
GNRP23 16 20 18 23 404D-22 ≤243 4 2.216 84*100
GNRP33 24 30 26 33 1103A-33G ≤210 3 3.3 105*127
GNRP50 36 45 40 50 1103A-33TG1 ≤212 3 3.3 105*127
GNRP65 48 60 52 65 1103A-33TG2 ≤211 3 3.3 105*127
GNRP73 52 65 58 73 1104A-44TG1 ≤207 4 4.4 105*127
GNRP88 64 80 70 88 1104A-44TG2 ≤213 4 4.4 105*127
GNRP103 75 94 82 103 1006TG1A ≤210 6 5.99 100*127
GNRP150 110 138 120 150 1006TAG ≤205 6 5.99 100*127
GNRP165 120 150 132 165 1006TAG2 ≤205 6 5.99 100*127
GNRP225E 165 206 180 225 1306C-E87TAG3 ≤220 6 8.7 117*136
GNRP250E 180 225 200 250 1306C-E87TAG4 ≤219 6 8.7 117*136
GNRP259E 188 235 207 259 1306C-E87TAG5 ≤221 6 8.7 117*136
GNRP275E 200 250 220 275 1306C-E87TAG6 ≤223 6 8.7 117*136
GNRP344E 250 313 275 344 2206C-E13TAG2 ≤201 6 14.6 137*165
GNRP388E 280 350 310 388 2206C-E13TAG2 ≤198 6 14.6 137*165
GNRP450E 320 400 360 450 2206C-E13TAG3 ≤201 6 14.6 137*165
GNRP500E 360 450 400 500 2506C-E15TAG1 ≤216 6 15 137*171
GNRP550E 400 500 440 550 2506C-E15TAG2 ≤211 6 15 137*171
GNRP625E 450 563 500 625 2806A-E18TAG1A ≤196 6 18.13 145*183
GNRP700E 508 635 560 700 2806A-E18TAG2 ≤203 6 18.13 145*183
GNRP800 580 725 640 800 4006-23TAG2A ≤199 6 22.921 160*190
GNRP900 640 800 720 900 4006-23TAG3A ≤200 6 22.921 160*190
GNRP1000 720 900 800 1000 4008-TAG1A ≤206 8 30.561 160*190
GNRP1125 818 1022 900 1125 4008-TAG2A ≤208 8 30.561 160*190
GNRP1375 1000 1250 1100 1375 4012-46TWG2A ≤212 12 45.482 160*190



Features:
1) Engine and alternator shall be mounted on a same frame steel skid
2) Built-in damper for anti-vibration
3) Small size, low weight, easy to operate, installation and maintenance
4) World most famous brand diesel engine: Perkins 1000 series engine-1003G, 1003TG, 1004TG, 1006TG1A, 1006TG2A, 1006TAG
5) World famous brand AC alternator: Stamford
6) Advanced and reliable control module: Key start, auto start

7) Full range protects function and alarm shutdown feature
8) According to professional standards



Soundproof/Silent Box:

1. Excellent ventilation

2. Oil tank mounted on base frame for 12 Hours working

3. Highly Corrosion Resistant construction

4. Excellent Access for Maintenance

5. Security and Safety

6. 1m<80DBA / 7m<70DBA



Control Panel:

1. Automatic control panel (AMF), LCD display

2. Four protection systems

3. Emergency stop



 Standard scope of supply:
Diesel engine(with all standard accessories, filters and electric system);
Radiator (with water tank and fan);
Alternator;
Control panel;
Steel base frame;
All above parts are assembled into a whole.

Other standard parts:
Effective muffle;
Exhaust elbow;
Belows;
Storage battery and connection wires;
Shock absorber;
Technical documents.
75kva-165kva Low rpm generator75kva-165kva Low rpm generator



75kva-165kva Low rpm generator75kva-165kva Low rpm generator75kva-165kva Low rpm generator
