Remote Start Fuction Power 110kva Diesel Generator
6BT5.9-G2 Cummins Engine
80KW/100KVA Prime Power
88KW/110KVA Standby Power
50Hz,1500RPM
GCS6410 AMF Control Model
|
Generator set |
Generator Model |
GNRC110 |
Rating Power (KW/KVA) |
80/100 |
|
Standby Power(KW/KVA) |
88/110 |
|
rating Ammeter(A) |
144 |
|
|
Diesel Engine |
Engine Model |
6BT5.9-G |
Prime Power(KW) |
92 |
|
Standby Power(KW) |
100 |
|
Bore X Stroke (mm) |
102×120 |
|
number of Cylinder & Configuration |
6 in line |
|
Displacement(l) |
5.88 |
|
Compression Ratio |
16.5 |
|
Aspiration Type |
Turbocharged |
|
Max. intake depression(mbar) |
6 |
|
Combustion air Volume(m³/min) |
5.8 |
|
Max. Exhaust back Pressure(mbar) |
10 |
|
Exhaust Gas Flow(m³/min) |
17 |
|
Max. Exhaust Gas Temperature |
576 |
|
Cooling Type |
Water cooled with Radiator |
|
Fan cooling air flow(m³/min) |
148 |
|
Total Coolant capacity(l) |
23 |
|
Max. temperature of coolant |
96 |
|
Max. permissible oil temp |
121 |
|
Total oil capacity(l) |
16.4 |
|
Rating Fuel Consumption(l/h) |
23 |
|
Governing Type |
Electrics Governor |
|
|
Alternator |
Rating Voltage(V) |
400/230 |
Alternator Model |
UCI274C |
|
Rating Capacity(KW/KVA) |
80/100 |
|
Eff.% |
89.6% |
|
Power Factor |
0.8 lagged |
|
Exciting type |
Brushless self-exciter, AVR |
|
Voltage regulation |
±1% |
|
No. of Phase |
3 phase 4 wire |
|
Enclosure Class |
IP21 |
|
Class of Insulation |
H |
|
Control Panel |
Control Module |
GCS6410 AMF Module |
Battery |
Rating Capacity(AH) |
2X100AH 12V |
Dimension |
Generator set dimension (LXWXH)(mm) |
2280X850X 1100 |
Weight |
Weight (kg) |
1400 |
Common steel base frame, Damper, Exhaust silencer, Flexible pipe, Battery connecting wires, Operation manual and document.
Optional Accessory
Circuit breaker, Starting Battery, Engine coolant and oil heater, Alternator space heater, Cooling for heat exchanger, Control system with RS232/485 communication interface, Battery charger by main supply, Fuel-water separator, Daily fuel tank, ATS & paralleling system, Soundproof Canopy and Moving Trailer.
Engine :
Original stamford alternator and certificate :
Open type Genset :
Silent Type Diesel Genset
