60kva to 800kva Open Frame Diesel Generator With Cummins Engine

60kva to 800kva Open Frame Diesel Generator with Cummins Engine

diesel engine

Engine: Cummins diesel engine

Rated voltage:  220V/380V, 230V/400V, 240V/415V

Rated frequency: 50/60Hz

Power factor: 0.8

Cooling method: closed water cooling

Starting method: electric start

Rated speed: 1,500/1,800rpm

Noise level:   68dB at 7m away

Alternator:

Brand: Stamford,LeroySomer, Marathon,Engga

Rated output:20KVA-2000KVA

Rated voltage: 400/230V

Rated frequency: 50/60Hz

Power factor: 0.8

Phase: 3-phase, 4-wire

Rated speed: 1,500rpm/1,800rpm

Excitation: harmonic excitation or phase compound or brushless

Voltage regulation: automatic

1.0% voltage regulation (maximum) in static conditions

Protection class:  IP21-23

Control panel

The generator control panel is manufactured locally

Standard engine instrumentation

Voltmeter with selector switch

Ammeter with selector switch

Frequency meter

Current transformers

Instrument fuses duly wired and ferruled

Mcb of suitable rating with overload and short-circuit protection

With AMF control panel or with ATS (automatic transfer system)

With EPA certification

Optional:

Trailer type

Soundproof / water proof

ATS (automatic transfer switch)

Parallel system

Remote system

Standard scope of supply:
Diesel engine(with all standard accessories, filters and electric system);
Radiator (with water tank and fan);
Alternator;
Control panel;
Steel base frame;
All above parts are assembled into a whole..
