Promotional Deutz Water Cooled Diesel Generator Set With Best Price

Promotional Deutz Water Cooled Diesel Generator Set With Best Price thumbnail-1
Promotional Deutz Water Cooled Diesel Generator Set With Best Price photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DEUTZ
Model Number:
GNRD
Contact Supplier Request Quote Chat Now
Shenzhen Genor Power Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name DEUTZ
Model Number GNRD
Output Type AC Three Phase
Speed 1500rpm or 1800rpm
Frequency 50Hz or 60Hz
Rated Power 10KW(12.5KVA) to 1600KW(2000KVA)
Rated Voltage 110V/220V, 220V/380V, 230V/400V
Rated Current 16A to 3036A

Specifications

1.Deutz Diesel Generator set
2.brushless 100% copper alternator
3.low fuel consumption
4.CE, ISO9001:2000

Deutz diesel generator set   can be coupled with A.C.synchronous brushless alternator such as Stamford, Leroy Somer,Marathon etc.



Genset Model Prime Power Standby Power Engine Fuel Consumption Cylinder No. Displacement Bore X Stroke
KW KVA KW KVA (g/kwh)  (L ) (mm)
GNRD18A 12 15 14 18 F2L912 ≤238 2 1.88 100*120
GNRD37A 28 35 30 37 F3L912 ≤232 3 2.82 100*120
GNRD41A 31 39 33 41 F3L913 ≤228 3 3 100*125
GNRD52A 38 47 42 52 F4L912T ≤228 4 3.77 102*125
GNRD55A 40 50 44 55 F4L913 ≤228 4 4.08 100*120
GNRD65A 48 60 52 65 F4L912T ≤228 4 4.08 102*125
GNRD75DA 50 62 60 75 BF4L912 ≤221 4 4.08 102*125
GNRD77A 55 69 62 77 F6L912 ≤228 6 5.65 100*120
GNRD85A 64 80 68 85 F6L913 ≤228 6 6.12 102*125
GNRD96A 72 90 77 96 F6L912T ≤228 6 6.12 100*120
GNRD102A 78 97 82 102 BF6L913 ≤228 6 6.12 102*125
GNRD144A 105 131 115 144 BF6L913C ≤228 6 6.12 102*125
GNRD50 37 46 40 50 D226B-3D ≤215 3 3 105*120
GNRD70 51 64 56 70 TD226B-3D ≤215 3 3 105*120
GNRD95 69 86 76 95 TD226B-4D ≤215 4 4 105*120
GNRD150 100 125 120 150 TD226B-6D ≤215 6 6 105*120
GNRD185 135 169 148 185 TBD226B6D ≤215 6 6 105*120
GNRD200 150 188 165 200 TBD234V6 ≤210 V6 10.8 128*140





Engine



1. Genuine Deutz  diesel engine

2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection

3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler

4. Machinery or electronic governing

5. Fuel injection pump

6. Electric motor starting system

7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner

8. Low discharge, and low fuel consumption

9. Installed conveniently and maintain easily


Alternator Features:
1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon,
2. Brushless, 4 poles, rotation magnet
3. IP21-23 enclose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: &le; &plusmn; 1% THF < 5%, low radio interference

Control System choice:
1. Common panle: With Unit voltage, tri-phase load current and frequency display. Water temperature and oil pressure display. Fuel level and fuel temperature display, with self-protection
2. Digital, Intelligentized panel. From manual start module, AFM module, to micro-computerize AMF/ATS and Automatic Parallel module, for meeting your different demand.

Soundproof canopy:
1)With steel sheet
2)Stainless steel locks
3)Control panel viewing window for monitoring the status of the generator set
4)Good ventilation system and anti-heat radiation construction
5)Effective anti-vibration devices to ensure the generator set run steadily
6)Super silent materials inside to ensure the noise lower than 70 dB 7 meters away
7)Emergency stop button mounted outside
8)Side lockable door easy for maintenance and installation
9)Lube oil and cooling water drains piped to exterior of the canopy

Accessories:
Standard accessories: Standard 40 radiator mounted on kid. Common steel frame, circuit nreaker, damper, exhaust silencer, flexible pipe,battery and connecting wire, Standard tool skit, operation manual and document.

Optional accessories: Engine collant and oil heater, alternator space heater, cooling for heating exchange, communictaion interface, battery charger by main supply,, ATS and paralleling system,silent canopy and moving trialer

Service scope:
OEM service, special pattern design service, 12 months warranty service.

Factory Inspection, the test items before delivery are mainly as follows:
1. Each generator set  should be put into commission more than 4 hours totally. They are tested on idle load, fully load and 10% overload.
2. The noise level is be tested.
3. All the metres on the control panel should be tested
4. The appearance of the gensets and all of the label and nameplate shall be checked.
