Specifications
Weichai Steyr Diesel Generator1)Steyr diesel engine,
2)Stable performance
3)water cooling
4)Energy saving
Weichai Steyr Diesel Generator
steyr the full range of products with high power ,torque,high reliability,low fuel consumption,low emission ,low noise ,adaptation sex strong characteristic
Prime output: 100-240KW/125-300KVA
Max output:110-264KW/137.5-330KVA
Selected Program:
Brief Introduction:
1) Prime output:180KW/225KVA Genset
2) Engine model: WD615.46D
Bore/stroke: 126/130mm
3) Alternator model: Stamford / Marathon/Landian/FDC
4) Cooling method: closed Water-cooled
5) Start method: Electrical
6) Speed governing method: Mechanical/Electronic
7) Intake method: Turbocharged-intercooled
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires
9) Frequency: <3%
10) Frequency at stable state: <1.0%
11) Frequency deviation at instantaneous state: ≤+10%
12) Frequency return time: ≤3s
13) Voltage deviation at stable state: ≤±1%
14) Voltage deviation at instantaneous state: ≤+20%
15) Voltage return time: ≤4s
16) Voltage modulation: ≤0.3%
17) Control system:
a) Automatic alarm system: acousto-optics test and alarm for start default,water over temperature, oil over temperature, over speed, oil over pressure and so on.
b) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers
18) Standard supply:
a) Diesel engine standard supply,
b) Alternator
c) Steel structure
d) Flange connector
e) Air cleaner, fuel cleaner, oil cleaner
f) On-board control panel
g) Set shock absorber
19) Optional Components:Engine protection module,parallel equipment,common base oil tank,electric governor,automatic start,automatic transfer switch(ATS),remote- control equipment,sound-proof / weather-proof canopy,trailer type.
.
