Specifications
1.ISO9001 CE approved2.OME offered
3.Alterntor:stamford
4.One year warranty
Generator set | Genset Model | GNRS-375 | |
Rating Power (KW/KVA) | 270KW/338KVA | ||
Standby Power(KW/KVA) | 300KW/375KVA | ||
Rating Ammeter(A) | 541.2A | ||
Diesel engine | General data | Engine model | 12V135AZD |
number of Cylinder & Configuration | 12V | ||
Bore X Stroke (mm) | 135X150 | ||
Displacement(l) | 25.8 | ||
Compression Ratio | 16:1 | ||
Governor type | Mechanic | ||
Rated speed (RPM) | 1500 | ||
Exhaust system | Exhaust gas tempreature(°C) | 480 | |
Air intake system | Aspiration Type | Turbocharged | |
Fuel system | Rating Fuel Consumption(g/KWh) | 232.6 | |
Fule standard | 0#light diesel | ||
Lubrication system | oil class | 15W40-CF4 | |
Starting method | 24V DC electric starting | ||
Alternator | Alternator model | stamford | |
Rating Voltage(V) | 400/230V | ||
Power factor | 0.8 | ||
No. of Phase | 3 phase 4 wire | ||
Enclosure Class | IP21 | ||
Class of Insulation | G | ||
Dimension | Generator set dimension (LXWXH) | 3500X1380X1900mm | |
Weight | Generator set Net Weight (kg) | 4100 | |
Engine Features of China Generator:
1. Chinese good brand diesel engine: shangchai dongfeng engine
2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection
3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
4. Machinery or electronic governing
5. Fuel injection pump
6. Electric motor starting system
7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
8. Low discharge, and low fuel consumption
Technical parameters of Control Panel:
Brand: Smartgen/ / Deepsea (Optional)
Start or Stop Generator set manually/ Automatically.
Generator over/under frequency protection
Open controller output can be defined as Pre-heat/Idle output .
Generator over/under/unbalance voltage Protection .
High Coolant temperature protection
Over speed protection
Low Oil pressure protection
Over current protection
Over load protection
Note: indicate this function depend on the set points of the controller in field.
