Thoyu Advanced Large and Small 4U Series Potatoes Harvester

Thoyu Advanced Large and Small 4U Series Potatoes Harvester thumbnail-1
Thoyu Advanced Large and Small 4U Series Potatoes Harvester photo-1
US$ 1,500 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Combine Harvester
Usage:
Potato Harvester
Contact Supplier Request Quote Chat Now
Zhengzhou Thoyu Import & Export Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Combine Harvester
Usage Potato Harvester
Place of Origin Henan, China
Brand Name Thoyu
Model Number TY4U-2A

Specifications

Working durable and efficiency;
High harvesting rate/low broken rate;
Sinple design, easy operation.

Components of Potato Harvester---Agriculture Harvester

The Potato Harvest Machine is composed of cutting seeding organization, filed wheels, girders, excavating a shovel, transporting chains, choosing sieve.



Features of potato harvester--- Agriculture Harvester

1. The Potato Harvester can integrally complete the working procedures such as harvesting, excavating, and choosing.

2. Most important thing is the series include the middle drive transmission and the left-side drive transmission, which are totally suitable different types of tractors!



Parameters of Potato harvest machine---Agriculture Harvester

Model

4U-1

4U-1A

4UZ

4U-2

4U-2A

4U2B

4U-3

Row number

Single row

Single row

Single row (vibration)

Double row

Double row

Double row

(Set pile)

Double row

(Auto loading)

Row spacing(cm)

55-80

50-60

55-80

55-80

55-80

55-80

55-80

Productivity(mu/hr)

3-5

         5-8

8-15

Total weight(Kg)

180

100

160

500

700

800

1200

Matching power(HP)

20-35

8-15(Walking tractor)

22-25

50

50

50

70

Working depth(cm)

25

20

25

25

25

25

25

Working width(cm)

60

60

60

130

160

REV of power(RPM)

560/1250

1000

560/1250

560

560

560

560

Dimension(cm)

240*90*90

90*70*70

120*100*75

280*220*100

280*220*100

280*220*100

330*390*310

Packing dimension

(cm)

210*88*73

85*70*65

150*90*70

220*190*80

220*190*80

220*190*80

320*200*130

Potato-exposing

rate(%)

                        ≥96%

Breakage rate(%)

                        ≤2%

Founction of potatos harvest machine--- Agriculture Harvester

1. Hang the harvester on the tractor which is 22-35hp.

2. Connecting the output pulley of the tractor and the input pulley of the harvester by veer belt at the same time.

3. Rolling the pulley by hands and see if it is blocked. If yes, please do be eliminating the blocks immediately.

4. Make sure the pinch roller has pressed on the belt well in case it loose during the process of elevating.

5. When operate the unequipped machine, please be stable and smooth.

6. Before starting to work, adjusting the height of the round to assure the digging height to be 10-15cm.



Photos of potatos harvest machine--- Agriculture Harvester

Thoyu advanced large and small 4U series potatoes harvesterThoyu advanced large and small 4U series potatoes harvesterThoyu advanced large and small 4U series potatoes harvesterThoyu advanced large and small 4U series potatoes harvesterThoyu advanced large and small 4U series potatoes harvesterThoyu advanced large and small 4U series potatoes harvester



After-sales Service:











              All products purchased in our company are guaranteed to keep in good repair for one year.



If quality problems happen in guarantee period, our company will maintain for free.







            Additionally, our company provides technical support and fittings for life. After-sales service



isn't restricted by time and we will solve your problems in time. If you are caught in some problems



when using our products, welcome to contact us at any time.
