2015 New arrival scrap tire processing production line /tire cleaning machine(Wechat:008613816026154)
- 30 Unit / Units per Month
- tire cleaning machine
- T/T Credit Card PayPal
Product Details
Condition: | New | Type: | Tire Machine | Tire Machine Type: | Tire Recycling Machine |
Place of Origin: | Henan, China | Brand Name: | Mayjoy | Voltage: | 220/380v |
Weight: | 1000kg | Certification: | ISO CE | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
MAYJOY tire cleaning machine widely used in processing waste tire,rubber,plastic,shoes production line
Principle of tire cleaning machine:
As many scrap tires scattered in many vehicles owner place, vehicle maintenance or waste recycling station,
but scrap tire must concentrated process,scrap tires quality in local are not sufficient worth investment in tires
and reclaimed rubber powder production line ,so there is a transportation problem, due to tire hollow, when
loading bulky and often with inadequate weight, resulting in a huge waste on transportation costs, waste tire
processing equipment due to small size and light weight, low cost dedicated to the scrap tires decomposition,
circle slicing,strips slicing, dice machine,such is a good solution to the problem of tires transportation high costs,
without affecting the next processing. Is ideal for primary processing equipment tires.
Introduction of tire cleaning machine:
Scrap steel wire and tire rubber powder equipment consist of tire circle incision machine, tire strip slicing
machine , tire block cutting machine, tire rubber crusher, magnetic separator, rubber powder mill, rubber
screening machine, screw feeder, with electrical cabinet nine parts. By waste tire decomposition facilities QKJ-1200 incision machine, first slice the steel tire by tire mouth, and then by the strip slice machine to slice the top
and lateral tire into strips, then rubber strip cut into 3 cm squares by the rubber block cutting machine , the cutting rubber block into the crusher into 2-10 mesh particles then by the screw feeder into the magnetic separator to separate the broken steel and rubber,
rubber particles automatically enters the powder mill, then screening, automatic feeding-stop automatic produce the rubber powder you need, advanced cycle milling technology , without any chemicals,
no gas, no water, low operating cost, is the best equipment for the use of steel wire tire rubber powder production .
Whole line processing :
1.Tire circle incision machine
incision machine for cutting down from one side of steel tire sidewall for next step cutting. The tire placed on
disc platform, rotating the handwheel and the jaw shelf holder will be firmly stuck inner tire, turn on the power,
rotating work platforms, cutting tools working as need, slowly cut into tires, step by step, until the cut sidewall
of the tire.
Electric power | Processing tire model | Processing capacity | Dimension(mm) | weight |
4KW | 750-1200 tire | 25-30pices/h | 1150*850*1200 | 0.5t |
2. Tire strip slitter
To cut the tire(remove sidewall) into strips, and the strips of width adjustable. Two disc cutter for special materials, hard and
durable, can use repeatedly grinding and use for no more than 1200 model steel tires.
Electric motor | capacity | Output size | Machine dimension (mm) | weight |
5.5KW | 0.8-1ton/h | 35*35*35mm | 780*550*1210 | 0.6ton |
3.Bar cutting machine
Machine can cut the tire strip into bar pieces, tool alloy cutting tools, nearly 9-16 tons per day, the cutting tool can be repeatedly grinding if not sharp.
Motor power | capacity | Output size | dimension | weight |
7.5KW | 0.8-1ton/h | 35*35*35mm | 780*550*1210mm | 0.6ton |
4.60B.Magnetic Separator
Model | KCXY -60B |
Roller effective length(mm) | 600 |
Working diameter roller(mm) | 320 |
Maximum magnetic induction (GS) | 3000 |
Cylinders Nos(pcs) | 1 |
Roller rotary speed(rpm) | 66,47,33 |
Produce rate(t/h) | 0.5-1.5 |
selected material size(mm) | 0.05-2.00 |
Motor type and power(kw) | Y801-4 0.75 |
Maximum outline size(mm) | 860×550×900 |
Total weight about (t) | 0.25 |
voltage(v) | 380 |
5. Conveyor
Mainly applied to the powder, granules, flakes of transport, supporting the crusher, mixer, extruder, storage
silos etc equipment, stable operation , long life, through time and material level to control and stop the
operation of the device. can also made by customer personal need.
Model | SSJ-3000 |
capacity | 800-1500kg |
power | 0.75KW |
weight | 260kg |
dimension | 3m*0.5m*0.4m |
6. PSJ-450 rubber crusher
According special requirements, developed a strong crusher machine which tools made of high quality steel ,
adapted to different kinds of materials and different coarse crushing hardness, the basic principle is: By
rotating blade and fixed blade knife the material is crushed and shear,finished product particles fineness
control by the screen , only to replacement screen, you can get the desired fineness finished particle ,
machine has air cooling dust removal system to ensure the quality of the material , we can according to
user needs, design and manufacture of response models .
Note: The in size of the feed material depends on the thickness, hardness and temperature
Motor power | Feeding size | Output size | capacity | Dimension(mm) | weight |
15kw | ≤20cm | 2-12mm | 200-800kg | 1600*1000*1500 | 0.8ton |
7. XMJ-6 Rubber Mill
consist of host, the motor frame shelf, water cooling system. The basic principle is by the relative motion of
the two discs, the material is cut, milled to achieve the purpose . Adopting of dual cooling water effectively
control crushed material temperature to obtain the desired product quality.
Model | Power | Inlet material size | Final fineness | capacity | weight |
XMJ-6 | 15kw | 5-20mesh | 20-120mesh | 150-200kg | 800kg |
8. Rubber Screening
Use features
It is mainly used for rubber granules, powder, sifted, with a compact, low dust, low noise, low power consumption
, easy to move and maintenance.
Model | SXJ-800 |
capacity | 50-800kg |
Sifted fineness | 5-120mesh |
power | 1.5kw |
weight | 280kg |
dimension | 4.5m×0.8m×1.0m |
9. Conveyor
Mainly applied to the powder, granules, flakes of transport, supporting the crusher, mixer, extruder, storage silos etc equipment, stable operation , long life, through time and material level to control and stop the operation of the device. can also made by customer personal need.
Model | LXJ-2000 |
capacity | 200-800kg |
power | 1.5KW |
weight | 220kg |
dimension | 2m*0.5m*0.4m |
10. 40A.small Magnetic Separator
Motor power | dimension | weight |
0.75kw | 1600*600*800mm | 0.15ton |
If you have interest or want more information on our tire cleaning machine ,please feel free to contact Lisa , i will reply u ASAP ! Best regards!
