hole punch shapes

1. Materials:

Steel, iron, aluminum, copper, stainless steel and

other metal plates and non-metallic sheet

2. Features:

Stamping made, net surface flat, smooth, beautiful,

strong and durable.

3. Hole pattern:

round, square, hexagonal, scale, rectangular, triangle, cross, slotted and etc.

4. Uses:

Mining, medicine, food selection, indoor sound insulation,

silencers, ventilation, grain storage, mechanical protection

5. Processing:

 mold, piercing, cutting, cutting edge, leveling, clean, surface treatment.

6. Specification:

(1)cold rolled steel sheet                                    (2)plate thickness:0.3mm-10mm

thickness:0.2mm-1mm                                            size:1.5x3m

length:1mm-20mm                                                  hole diameter:0.8mm-100mm

hole diameter:0.8mm-10mm

7. Thickness or Gauge

Thickness of the matel sheets do not change during the perforation. Normally thickness is expressed in gauge, please see the picture. However, to avoid possible misunderstanding, we would suggest to express them in inches or millimeters.

8. Width and Length

The most common width and length are as follows:

1000mmX2000mm

1220mmX2400mm

1250mmX2500mm

1250mmX6000mm

1500mmX3000mm

1500mmX6000mm

However, we also manufacture other sheet sizes according to clients' requests.

9. Margins

Margins are the blank (un-perforated) area along the edges of the sheet. Normally the margin on the length are 20mm minimum, and margin along the width can be 0 minimum, or at clients' requests.

10. Hole Arrangement

Round holes are normally arranged in 3 types. Other hole patterns and hole arrangements can be custom made.

11. Round hole specifications for reference:
