storage containers
Material: low carbon steel wire, stainless steel wire
Wire diameter: 2.0mm-6.5mm
Surface treatment: Zinc coated,pvc coated
Colour: black,white ,orange ,red ,green, blue (as your request)
Characteristic of the products:
(1) make use of space as the storage for goods. do not takes up a lot of space.
(2)Can use in supermarket to exhibit the goods.
(3)Stacking up to 4 layers high, easy storing.
(4)Suitable for varied transportation equipment and automatic warehouse conveyer belt. This will save cost and labors expense
(5)Can fold for stacking up when is not using .
The specification of wire container:
| Item |
External Size L×W×H(mm) |
Wire (mm) | Mesh(mm) |
Load Bearing (kg) |
Stacking (Layers) | Estimated Weight(kg) | 20'GP(pcs) | 40'GP(pcs) |
| A-5 | 1000*800*840 | 6.0 | 50*50 | 1200 | 4 | 49 | 230 | 480 |
| B-5 | 1000*800*840 | 6.4 | 50*50 | 1500 | 4 | 54 | 230 | 480 |
| B-5 1/2 | 1000*800*500 | 6.4 | 50*50 | 1000 | 4 | 40 | ||
| C-5 | 1000*800*840 | 4.8 | 50*50 | 500 | 4 | 37 | 230 | 480 |
| S-5 | 1000*800*840 | 6.4 | 50*100 | 1000 | 4 | 45 | 230 | 480 |
| SS-5 | 1000*800*840 | 6.0 | 50*100 | 1000 | 4 | 42 | 230 | 480 |
| A-7 | 1200*1000*890 | 6.0 | 50*50 | 1500 | 4 | 65 | 158 | 325 |
| B-7 | 1200*1000*890 | 6.4 | 50*50 | 2000 | 4 | 80 | 158 | 325 |
| S-7 | 1200*1000*890 | 6.4 | 50*100 | 1000 | 4 | 62 | 158 | 325 |
| SS-7 | 1200*1000*890 | 6.0 | 50*100 | 1000 | 4 | 57 | 158 | 325 |
| A-3 | 800*600*640 | 6.0 | 50*50 | 800 | 4 | 32 | ||
| C-2 | 800*500*540 | 4.8 | 25*50 | 500 | 4 | 27 | |
Who you are?
1. We are JINTONG WIRE MESH FACTORY .
2. Mainly products are: perforated mesh series, farm products series, fencing products series, and machine series, etc.
3. Occupied area:7,000 square meters.
Why choose us?
Professional wire mesh factory since 1992 years.
Reasonable Price with Quality assurance. Timely delivery; Close service.
Sophisticated production equipment.
Professional staff and the management of the production workers Strictly quality control inspection system
