Collapsible wire mesh container
The Folding Wire Mesh Container, also names as wire mesh basket or wire mesh cage is an essential and flexible unit for material handling and storage. It's lightweight yet can hold up to 4,000 lbs. , durable yet low cost, can be used for a multitude of tasks yet is virtually maintenance free.
Examples of custom-built Wire Mesh Container options:
1. Cap channel over wire perimeter for added protection
2. Square-Stack legs for secure stacking
3. Tags, labels, card holders
4. Casters, fork sleeves, runner bars
5. Dividers or security lids
6. Custom colors
7. Custom feet available.
8. Custom wire mesh size
Regular size (unit mm):
Item | Outer Size (LxDxH) | Mesh (mm) | Diameter (mm) | Load (kgs) | Net weight (kgs) | Quantity per 40’ GP |
XFW-A1 | 812X508X558 | 25X25 | 3 | 300 | 19 | 696 |
XFW-A3 | 800x600x640 | 50x50 | 6.0 | 800 | 32 | 696 |
XFW-A5 | 1000x800x840 | 50x50 |
6.0 | 1300 | 49 | 484 |
XFW-A7 | 1200x1000x890 | 50x50 | 6.0 | 1500 | 65 | 270 |
XFW-B5 | 1000x800x840 | 50x50 | 6.4 | 1500 | 55 | 440 |
XFW-B7 | 1200x1000x890 | 50x50 | 6.4 | 2000 | 71 | 270 |
XFW-S5 | 1000x800x840 | 50x100 | 6.4 | 1200 | 47 | 484 |
XFW-C2 | 800x500x540 | 25x50 | 4.8 | 500 | 25 | 832 |
XFW-A4 | 1000x600x640 | 50x50 | 6.0 | 1000 | 37 | 496 |
XFW-A71 | 1256X1060X1140 | 50x50 | 6.0 | 1500 | 87 | 200 |
XFW-S6 | 1200x800x840 | 50x100 | 6.4 | 1200 | 53 | 330 |
XFW-A8 | 1200x1200x890 | 50x50 | 6.0 | 1500 | 69 | 200 |
XFW-O5 | 1000x800x840 | 50x50 | 5.6 | 1000 | 44 | 484 |
XFW-AS9 | 2000X1200X890 | 50X100 | 6.0 | 800 | 86 | 135 |
Regular size in US
Item | Size | Mesh pattern | Capacity | Quantity in 40' HC |
Extra large container | 40'x48'x42' | 2'x2' | 4000lbs | 306 |
Senior container | 40'x48'x36' | 2'x2' | 4000lbs | 306 |
Medium container | 32'x40'x34' | 2'x2' | 4000lbs | 500 |
Junior container | 20'x32'x22' | .5'x.5' | 1100lbs | 648 |
