High speed full automatic chain link fence machine,chain link wire mesh machine(ISO9001)
Multifunctional Chain link wire mesh (chain link fence/Diamond wire mesh)Machine:
Main technical data of multifunctional diamond wire mesh machine:
1. Outside dimensions: Length: 3200mm, width: 750mm, height: 850mm
2, Maximum working platform: 2000mm, maximum weaving width: 2000mm
3, Maximum weaving aperture: 200 x 200 mm, minimum weaving aperture: 4 x 4 mm
4, Maximum wire diameter: 6.0mm, minimum wire diameter: 0.4mm
5, Power for Model A: 1.5 KW, for Model B: 0.8 KW.
Semi-automatic Chain link wire mesh(chain link fence/Diamond wire mesh)Machine:
Semi-automatic chain link fence machine is easy for operation and control. The surface of the chain link fence is flat after being arranged. This machine has reliable property, less troubles and easy maintenance. It is suitable for small enterprises.
Main technical data:
1. Outside dimensions: Length: 2400mm, width: 4400mm, hight: 2500mm
2, Maximum working platform: 8000mm, maximum weaving width: 8000mm
3, Maximum weaving aperture: 52x52mm
4, Maximum wire diameter: 4.0mm, minimum wire diameter: 1.0mm
5, Power: 3KW/ set, 0.12KW/set
6, Productivity: 15-20 m2 /hour
7, Total weight: 1.5T.
Fully Automatic Chain wire mesh(Chain link fence/Diamond wire mesh)Machine:
Spider brand fully automatic chain link fence machine we produce is made with adaptation of Germany technology. This machine offers high productive efficiency and reliable quality chain link fence products with reasonable design, using computer control, mechanical and electrical integration, automatic control of wire feeding, cutting, rolling and edge treatment. Import advanced technology and domestic machinery prices make this machine an ideal choice for chain link fence producers.
Main Technical Data:
1. Capacity: (square meter/hour) 25-60
2, Steel wire diameter: (mm) Φ2.0Φ4.0. Wire feeding number: double wires. Note: The steel wire meets the standard: GB3081-82 YB544-65 Steel Wire Material: B 1 F-B 3F
3, Chain link fence roll width: (mm) 600-2000, at any length
4, Power: electric motor: 3.0KW one set, 4.0KW one set, 0.12 KW one set
Netting width |
600-4000mm |
Wire diameter |
2-4.0mm |
Outline dimension |
Length 6500mm width 4500mm height 2500mm |
Mesh size |
40*40-100*100mm |
Motor power |
4kw |
Weight |
4.1t |
Productivity |
80-120square meter/h |
Netting width |
600-2000mm |
Wire diameter |
2.5-4.0mm |
Outline dimension; |
Length 4500mm width 4500mm height 2500mm |
Mesh size |
50*50-100*100mm |
Motor power |
3kw |
Weight |
3.5t |
Productivity |
60-80square meter/h |
1. Payment term: T/T, L/C, Western Union
2. Payment terms: 30% by T/T should be paid in advance, the balance payment paid againest the copy of B/L
3. Delivery time: shipping products within ten days, or negotiate according to total quantity.
4. Min order quantity: 1 SET, or by negotiate with each other
Inquiry response: Your inquiries will be replied in 24hours
Sample support: Free samples are available in 3-5days
With the development in production technology.All kinds of wire mesh and wire that we produced have reached advanced level.
the products are exported to Southeast Asia, the Middle East, Canada, the United States and other countries and regions.
Our company rely on the high quality, good reputations, the high quality after sale service.
we get the best reputations from most of our customers.
Following are some photos which shown our meeting with customers.
