Wire butt welding machine
This machine forging metal materials can be low-carbon steel, high carbon steel, alloy steel, stainless steel and other non-ferrous metals and alloys can flash butt welding. the surface of wire can not be influenced, and the intensity of anti-bending and tensile strength is higher than parent metal. Meanwhile, it has the function of wire annealing.
Main Parameter:
Wire diameter Wire diameter |
5.0-10.0mm |
Primary voltage: |
220/380v |
Rated capacity: |
16Kva |
Duty cycle: |
20% |
Rated current of primary winding: |
42A |
Steps of regulation: |
8 |
Max. upset force: |
15kg |
Max. stroke of feeds |
70mm |
Max. opening of fixture |
50mm |
Tmes of welding per hour |
65 |
Net weight |
approx.130kg |
overall dimentions(Lx WxH): |
1100x600x500mm |
Free fumigation safe Wood case package. or as customer's detail request.
Related Machine:
wire Drawing mchine pointing machine
water tank wire drawing machine wire straightening and cutting machine
Inquiry response: will be replied in 24hours
We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our technician to help install the machines in your country, and also could supply all the spare parts with cost price if customer need.
- OEM and ODM: changing on design , color , acceptable(welcome )
- develop on artwork and sketch : acceptable
- Delivery time: 1 week for our own design. 15-25days for cusmoized model.
- Payment terms: T/T, L/C, Western Union
- MOQ: 1set can be acceptable for trail order.
- Over 3sets can have wholesale price. Welcome to join us as our sales agent in your market.
Who you are?
1. We are JINTONG WIRE MESH FACTORY .
2. Mainly products are: perforated mesh series, farm products series, fencing products series, and machine series, etc.
3. Occupied area:7,000 square meters.
Why choose us?
Professional wire mesh factory since 1992 years.
Reasonable Price with Quality assurance. Timely delivery; Close service.
Sophisticated production equipment.
Professional staff and the management of the production workers Strictly quality control inspection system.
QA/QC Introduction:
We have passed the ISO 9001:2008 in the year of 2011 and also have quality supervision staff to monitor
the production process.
- QA/QC Introduction-- JINTONG FACTORY Strictly control quality inspection.
- Quality inspection department work is to inspect quality each day in production workshop.
- We must ensure that every product to attain to the quality requirements of the customers.
- We can pass the third party to test the product quality, and ensure that the quality meet the customers' requirements.
With the development in production technology, All kinds of wire mesh and wire that we produced have
reached advanced level, the products are exported to Southeast Asia, the Middle East, Canada, the United States
and other countries and regions, Our company rely on the high quality, good reputations, the high quality after
sale service,we get the best reputations from most of our customers.
Following are some photos which shown our meeting with customers.
