Product Description

Specifications

Industiral Long Distance HF RFID reader&Writer
ISO15693 13.56MHZ
Multi Tag Reading
Specialzied For Library application

GENERAL DESCRIPTION.. 1

HYH1W1TR is a high performance ISO15693 protocol HF tag reader. It is designed upon fully self-intellectual property. Based on proprietary efficient anti-collision algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, personnel identification, conference attendance system, access control, anti-counterfeit and industrial production process control system.

FEATURES

l Self-intellectual property;

l Support mainstream ISO15693 protocol tag (TI, PHILIPS, ST, INFINEON, FUJITSU, EM…);

l Advanced anti-collision algorithm. High identification rate with tag processing speed 30~50pcs/s);

l SMA RF interface to support standard 50ohm RFID antenna. Effective distance up to 70cm;

l Support TRANSPARENT COMMAND;

l Support SCAN MODE;

l Support optional DPPM and WPPM;

l Low power dissipation with single +12 DC power supply;

l RF output power over 1W;

l Provide RS232 or RS485 communication port;

l 8 bits reader address facilitating multiple readers network;

l Built-in Relay

CHARACTERISTICS

l Absolute Maximum Rating

ITEM	SYMBOL	VALUE	UNIT
Power Supply	VCC	16	V
G_IN1,G_OUT1,G_OUT2 I/O Voltage	V_IO	7	V
Operating Temp.	T_OPR	-25~+60	°C
Storage Temp.	T_STR	-25~+80	°C

l Electrical and Mechanical Specification

Under T_A=25°C,VCC=+12V unless specified

ITEM		SYMBOL	MIN	TYP	MAX	UNIT
Power Supply		VCC	11.5	12	15	V
Current Dissipation		I_C		350	450	mA
Frequency		F_REQ		13.56		MHz
Effective Distance^*		DIS	0	700	850	mm
G_IN1 Input Level		V_IH V_IL	3.5	2.6 2.3	1.55	V V
G_OUT1, G_OUT2 Output Current		±I_O			5	mA
G_OUT1,G_OUT2 Output Level		V_OH(I_O=-5mA) V_OL(I_O=5mA)	3.95		0.73	V
Relay	Rated Load	C_LOAD			0.5A at 125VAC 1A at 24VDC
	Operating Voltage				125VAC 60VDC	V
	Operating Current				1	A
Size		L x W x H		116 x 104 x 27		mm

*Effective distance depends on antenna, tag and working environment.
