Automatic Check-in Device Personnel School Attendance System Rfid hf Reader Gate Reader Gate Attendance Access Control

HF RFID GATE READER

HYL50C

Specification

HYINTECH Automatic Attendance System is barrier-free and automatically check-in device designed for conference, exhibition and other events. This system is integrated with HYINTECH high-performance reader and infrared sensor, can rapidly and accurately identify personnel in/out with or without cards. It can identify ISO/IEC15693 and ISO18000-3 tags. The widest identification distance can be up to 120 cm (exact distance depends on tag and working environment ).

Main Features

• Ø         Working Frequency: 13.56Mhz
•
• Ø         Compatible Protocol: ISO15693 and ISO18000-3 protocol
•
• Ø         Passage Width: 70~120cm (adjustable according to user’s demands)
•
• Ø         Radio Frequency Power: 3~8W(adjustable)
•
• Ø         With noise detection function to detect electromagnetic interference around
•
• Ø         Integrated infrared sensor cutting analysis, can rapidly and accurately identify personnel in/out with or without cards and to prevent their followers
•
• Ø         Communication Interface: Ethernet and RS232 port.
•
• Ø         Built-in sound and light alarm/prompt function.
•
• Ø         Power Supply: AC 100~240V
•
• Ø         Transparent acrylic design, looks beautiful and elegant

Key Parameters
